Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 3600 x 1200 x 750 mm | |
|---|---|---|
| Per-seat work surface | 1200 x 600 mm | |
| Desktop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Desktop privacy divider height | 450 mm | |
| Under-desk knee clearance height | 680 mm | |
| Mobile pedestal dimensions | 420 x 480 x 725 mm | |
| Steel leg section | 40 x 35 mm | |
| Cable grommet diameter | 80 mm | |
| Lower crossbar ground clearance | 100 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 200 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Recommended user count | 6 | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Unit net weight reference | 260 kg | |
| Frame static load rating | 600 kg | |
| Pedestal drawer static load | 30 kg | |
| Castor load rating per wheel | 40 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E0 grade particleboard core | |
|---|---|---|
| Worktop surface | Thermally fused melamine laminate | |
| Edge protection | Color-matched PVC edge banding | |
| Support frame | Powder-coated white steel | |
| Privacy dividers | Fabric-upholstered fiberboard core | |
| Central cable spine | Powder-coated steel channel | |
| Mobile pedestals | Steel construction with lockable castors | |
| Hardware fittings | Zinc-plated steel cam locks and connectors | |
| Levelling glides | Nylon base adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating layout | Face-to-face 3+3 configuration | |
|---|---|---|
| Cable management system | Integrated central under-desk channel with grommets | |
| Mobile pedestal storage | Rolling 2-drawer cabinets per position | |
| Privacy screening | Upright desktop dividers between opposing users | |
| Frame structure | Shared goal-post leg modules | |
| Floor leveling | Adjustable glide feet on frame bases | |
| Pedestal mobility | 360-degree swivel lockable castors | |
| Modular expansion | Compatible with matching bench modules | |
| Central cable access | Removable channel covers | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan corporate office team zones | Dense 6-person layout for project teams requiring close collaboration | |
|---|---|---|
| Call center and shared service floors | Standardized high-density seating with reduced visual distraction | |
| Startup and co-working spaces | Flexible modular seating that can be reconfigured as team size changes | |
| Administrative back-office areas | Dedicated workstations with integrated personal filing storage per user | |
| Temporary project team spaces | Quick-to-assemble bench units for short-term cross-functional teams | |
| Small business open offices | Cost-effective clustered seating with integrated cable management for neat work areas |
EU Market Access Requirements* EN Standards
| Office worktable safety requirement | EN 527:2011 | |
|---|---|---|
| Office worktable dimensional requirement | EN 527:2002 | |
| Furniture formaldehyde emission | EN 13986:2004 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| Office desk dimensional standard | GB/T 3326 | |
|---|---|---|
| Wood-based panel formaldehyde limit | GB 18580 | |
| Furniture surface durability standard | GB/T 4893.8 | |
| Office furniture mechanical stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Office desk dimensional standard: GB/T 3326; 2. Wood-based panel formaldehyde limit: GB 18580; 3. Furniture surface durability standard: GB/T 4893.8; 4. Office furniture mechanical stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
