Automatic mm / inch conversion · Core engineering specifications
| Overall cluster dimensions | 4080 x 2400 x 1100 mm | |
|---|---|---|
| Standard worksurface height | 750 mm | |
| Individual workstation width | 1200 mm | |
| Individual workstation depth | 600 mm | |
| Worksurface thickness | 25 mm | |
| Desktop privacy screen height | 300 mm | |
| Knee clearance height under worksurface | 673 mm | |
| Central divider shelf unit height | 1100 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel leg section dimensions | 40 x 35 mm | |
| Under-desk drawer internal height | 250 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total cluster net weight | 350 kg | |
|---|---|---|
| Single worksurface static load capacity | 91 kg | |
| Central divider shelf static load per tier | 20 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Maximum user weight per workstation | 113 kg | |
| Finish abrasion resistance rating | 2000 cycles | |
| Seated user capacity | 6 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface substrate | 25mm particle board core | |
|---|---|---|
| Worksurface finish | Light oak wood grain thermally fused melamine | |
| Frame and leg construction | 1.8mm thick powder-coated off-white steel | |
| Divider and storage panel material | 18mm MDF with matching melamine finish | |
| Edge protection | 2mm color-matched PVC edge banding | |
| Desktop privacy screens | 300mm high gray fabric-wrapped fiberboard | |
| Drawer hardware | Cold-rolled steel ball-bearing slides | |
| Cable management components | ABS plastic wire grommets and routing channels | |
| Lock hardware | Keyed cam locks for under-desk drawers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Workstation layout | Back-to-back two-row design with 3 seats per row for 6 total users | |
|---|---|---|
| Central divider storage | Two-tier open shelving plus lockable under-desk drawers per seat | |
| Privacy screening | Low desktop dividers between adjacent same-row seats | |
| Cable management | Desk surface grommets and under-desk routing channels | |
| Under-desk CPU storage | Dedicated open bay per workstation for desktop computer towers | |
| Modular connectivity | Pre-drilled interlocking connectors for assembly and layout expansion | |
| Leveling adjustment | Threaded floor glides on leg bases for uneven floor compensation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office spaces | High-density 6-person cluster for corporate team zones and startup work floors | |
|---|---|---|
| Call centers and admin departments | Low dividers balance privacy and easy team communication between adjacent seats | |
| Co-working facilities | Modular design supports dedicated team booking zones with integrated storage | |
| New office fit-out projects | All-in-one unit includes work surfaces, dividers and storage for fast deployment | |
| Educational institution staff offices | Stable construction and file storage suitable for administrative and faculty work areas | |
| Recommended pairing | 6 ergonomic mesh office chairs with 5-star base and adjustable height |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for commercial work surfaces | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional, ergonomic and performance requirements | |
| EN 1335-1:2020 | Office furniture ergonomic dimensional criteria for seated workstation clearances |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer, shelf and cabinet performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applies to desk panels and storage components | |
|---|---|---|
| GB/T 3325-2017 | Metal office furniture structural safety standards, applies to steel frame and support legs | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applies to desk panels and storage components; 2. GB/T 3325-2017: Metal office furniture structural safety standards, applies to steel frame and support legs; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
