PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2400 × 1500 × 1150 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Workstation net weight	96 kg
Distributed desktop load per person	80 kg
Central pedestal top load	45 kg
Each drawer load capacity	20 kg
Lower cabinet shelf load	30 kg
Seating capacity	4 users
Privacy screen impact resistance	20 kg lateral static load
Floor contact points	8 points
Recommended daily user load cycle	8 hours per position
Top Static Load Reference	150 kg uniformly distributed

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surfaces	25 mm melamine-faced particleboard with sealed 2 mm PVC edges
Central pedestal	Melamine-faced engineered-wood cabinet with two drawers and lower enclosed storage
Support legs	Powder-coated steel round tapered legs with floor glides
Privacy screens	Rigid dark divider panel with light lower support rail
Drawer hardware	Steel side-mounted drawer slides with integrated key locks
Cable and equipment fittings	Steel/aluminium rail and grommet hardware behind the desktop divider

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Four-position work layout	Two back-to-back desktop pairs provide four seated work zones separated by central storage and dividers
Central lockable storage	Two key-lock drawers and a lower enclosed cabinet provide personal or team storage at the shared spine
Desktop privacy separation	Dark vertical screens reduce visual distraction between facing users and help define individual zones
Cable management route	Rear rails and desktop grommets route monitor and laptop cables toward the central pedestal

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office cluster	Suited to four staff in compact open offices where shared storage and visual separation are required
Administrative or clerical workspace	Supports laptop, monitor, keyboard and document tasks at each 1200 mm-wide position

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Apply safety, strength and durability requirements for office desks
EN 527-2:2014	Use dimensional guidance for office work surfaces, leg room and seated clearance
EN 15372:2016	Use durability, strength and stability requirements for non-domestic storage furniture
EN 13986:2004+A1:2015	Use construction-panel characteristic and conformity reference for wood-based panels

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Use desk products performance test reference for loads, stability and cyclic forces
ANSI/BIFMA X5.9-2019	Use storage performance reference for drawer operation, locks and cabinet loading
ANSI/BIFMA e3-2019	Use furniture sustainability and material-transparency scoring reference during tender evaluation

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	Use as dimensional, construction and inspection reference for wooden office furniture
GB/T 3325-2017	Use for metal furniture strength, durability and safety acceptance planning
GB 18580-2017	Use formaldehyde emission acceptance reference for wood-based panels
GB/T 10357 furniture test series	Use desk strength, stability and durability test methods during procurement validation

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: Use as dimensional, construction and inspection reference for wooden office furniture;
2. GB/T 3325-2017: Use for metal furniture strength, durability and safety acceptance planning;
3. GB 18580-2017: Use formaldehyde emission acceptance reference for wood-based panels;
4. GB/T 10357 furniture test series: Use desk strength, stability and durability test methods during procurement validation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-2P-CENTRAL-2400

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-2P-CENTRAL-2400

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-2P-CENTRAL-2400Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Person Back-to-Back Office Workstation with Central Pedestal and Dividers, model WS-2P-CENTRAL-2400, presents an organized four-position workspace arranged as two back-to-back desktop pairs. Its central storage pedestal forms the shared spine, while dark vertical privacy screens separate facing users and help define individual work zones. The result is a compact, structured layout suited to teams that benefit from shared support storage with reduced visual distraction. Each main seat position offers 1200 mm of working width, with effective knee clearance of 680 mm in height and 900 mm in width. The workstation uses melamine-faced engineered wood for its work surfaces and pedestal, creating a consistent practical office finish. Work surfaces are made from 25 mm melamine-faced particleboard with sealed 2 mm PVC edges, and the finished top thickness is 50 mm. The round tapered support legs are powder-coated steel with floor glides; each main leg section is 80 mm with a 2 mm metal wall. Privacy divider panels are available with fabric or acrylic screens, presented here as rigid dark panels supported by a light lower rail. At the center, the melamine-faced engineered-wood pedestal includes two drawers and lower enclosed storage. Drawers operate on steel side-mounted slides and include integrated key locks, giving users personal or team storage directly within the workstation. Cable management is integrated behind the desktop divider through steel or aluminium rail hardware and desktop grommets. Monitor and laptop cables can be routed toward the central pedestal, while the 80 mm diameter cable openings and 120 mm-deep cable tray support orderly equipment setup. The configuration is appropriate for compact open-plan office clusters housing four staff, administrative or clerical workspaces, and residential settings arranged for regular desk-based work. It supports laptop, monitor, keyboard, and document tasks at each seated position. Procurement planning should account for the four-user capacity, the need to assemble the set on site, and the workstation’s 96 kg net weight. Load allowances include 80 kg distributed desktop load per person, 45 kg on the central pedestal top, 20 kg per drawer, 30 kg on the lower cabinet shelf, and 20 kg lateral static load resistance for the privacy screen. Reference packaging notes two cartons for one set in one summary entry, while logistics details also record four cartons and 180 kg packaged gross weight, so buyers should confirm packing configuration and delivery access before ordering.

Two-Person Back-to-Back Office Workstation with Central Pedestal and Dividers Specifications
