| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (W x D x H) | 1800 x 1600 x 1100 mm | |
|---|---|---|
| Main worksurface height | 750 mm | |
| Main worksurface depth | 800 mm | |
| Credenza return depth | 500 mm | |
| Desktop privacy divider height above surface | 350 mm | |
| Seated knee clearance height under worksurface | 650 mm | |
| Worksurface panel thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Splayed steel leg wall thickness | 1.5 mm | |
| CPU storage compartment internal dimensions | 250 x 500 x 450 mm | |
| Open upper shelving clearance height | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Unit net weight | 110 kg | |
|---|---|---|
| Worksurface static distributed load capacity | 100 kg | |
| Lockable drawer slide load rating | 25 kg | |
| Drawer slide open/close cycle rating | 50000 cycles | |
| Cabinet door hinge open/close cycle rating | 80000 cycles | |
| Leveling foot adjustment range | 10 mm | |
| Recommended user weight capacity | 130 kg | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Limited commercial warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worksurface panel | 25mm E0-grade melamine-faced MFC | |
|---|---|---|
| Credenza storage carcass panels | 18mm E0-grade melamine-faced MFC | |
| Desk support legs | 1.5mm thick powder-coated steel, splayed A-frame design | |
| Desktop privacy divider screen | Fabric-wrapped MDF core panel, warm brown finish | |
| Edge banding | 2mm thick PVC edge tape, brown accent trim | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Cabinet door hinges | Cold-rolled steel soft-close concealed hinges | |
| Leveling feet | Nylon-tipped adjustable steel feet | |
| Hardware (locks, screws, connectors) | Zinc-plated steel | |
| Cable management grommets | ABS plastic | |
| Cabinet door and drawer fronts | 18mm melamine-faced MFC, off-white finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Seated work surface support | Provides 750mm height ergonomic platform for monitor, keyboard and office tasks | |
|---|---|---|
| Desktop privacy partition | 350mm tall brown screen blocks cross-desk line of sight for seated users | |
| Integrated credenza storage zones | Includes open upper shelves, lockable drawer, lower cabinets, dedicated CPU bays | |
| Lockable drawer security | Keyed lock secures private documents and small valuables in top left drawer | |
| Cable management routing | Integrated channels route power/data cables from desktop to floor via leg openings | |
| Floor leveling adjustment | Adjustable feet on credenza and leg bases compensate for uneven office flooring | |
| CPU compartment access | Open-front bays allow easy access to desktop tower power buttons and ports | |
| Modular configuration flexibility | Supports left or right credenza return orientation for open plan office layouts | |
| Drawer/cabinet handle lock diameter | 20 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff workstations | Provides individual work zones with integrated storage for team office environments | |
|---|---|---|
| Home office professional workspaces | Offers sufficient storage and work surface for remote professional work setups | |
| Co-working space dedicated desks | Modular design supports flexible individual work zones in shared office facilities | |
| Small business executive or admin work areas | Combines work surface and storage to fit compact office footprints | |
| Startup office general work positions | Cost-effective commercial-grade desk with built-in storage for growing teams | |
| Reception back-office work areas | Provides organized storage and work surface for administrative staff tasks |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to load and stability testing | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office worktables dimensional requirements, applicable to ergonomic height and clearance | |
| EN 13722:2004 | Formaldehyde emission classification for wood-based panels, applicable to MFC panel acceptance | |
| EN 15372:2016 | Furniture durability, strength and stability for non-domestic storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for drawer and cabinet cycle testing | |
| ANSI/BIFMA X7.1-2022 | Formaldehyde emission standard for low-emitting office furniture materials |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and storage carcass quality | |
|---|---|---|
| GB/T 3326-2016 | Desk, chair and bench dimensional standards, applicable to worksurface height and clearance verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E0-grade MFC material acceptance | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable to melamine laminate durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and storage carcass quality; 2. GB/T 3326-2016: Desk, chair and bench dimensional standards, applicable to worksurface height and clearance verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E0-grade MFC material acceptance; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable to melamine laminate durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
