| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 1400 x 700 x 750 mm | |
|---|---|---|
| Desktop panel thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Storage pedestal dimensions | 450 x 700 x 700 mm | |
| Knee clearance height | 620 mm | |
| Knee clearance width | 750 mm | |
| Privacy divider dimensions | 1200 x 400 mm | |
| CPU compartment dimensions | 250 x 500 x 450 mm | |
| Angled steel leg cross-section | 50 x 30 mm | |
| Drawer front accent panel height | 150 mm | |
| Cable grommet diameter | 60 mm | |
| Adjustable foot height | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 120 kg | |
|---|---|---|
| Drawer slide load rating | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| CPU compartment static load | 40 kg | |
| Desk net weight reference | 68 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user weight | 136 kg | |
| Limited warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 25mm E1-grade particleboard | |
|---|---|---|
| Desktop surface finish | 0.6mm melamine laminate | |
| Support legs and frame | 1.2mm thick powder-coated white steel | |
| Privacy divider core | 12mm polyester fiber acoustic panel | |
| Drawer and cabinet panels | 18mm engineered wood with white laminate | |
| Drawer runners | Cold-rolled steel ball-bearing slides | |
| Cabinet lock hardware | Zinc alloy keyed cam lock | |
| Adjustable leveling feet | Nylon base with steel threaded stem | |
| CPU compartment dividers | 0.8mm brushed steel panels | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Fixed-height work surface | 750mm standard office height, optimized for seated task work with ergonomic office chairs | |
|---|---|---|
| Half-width privacy divider | Desk-mounted screen blocks line of sight between adjacent workstations | |
| Lockable storage pedestal | Keyed lock secures upper supply drawer and lower file cabinet for personal items | |
| Dual CPU storage compartment | Open under-desk bay holds two mid-tower computers with front access | |
| Integrated cable management | 60mm desktop grommet routes power and data cables under the work surface | |
| Soft-close drawer operation | Ball-bearing slides prevent slamming and provide smooth pull-out access | |
| Floor leveling adjustment | 10mm height adjustment on pedestal feet eliminates desk wobble | |
| Available color options | 3 | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office work zones | Single-seat workstation for staff cubicle arrangements with visual privacy divider | |
|---|---|---|
| Home office dedicated workspaces | Compact integrated storage unit for personal document and computer storage | |
| Small business staff workstations | Cost-effective fixed-height desk for daily administrative and computer tasks | |
| Startup flexible office layouts | Light neutral color scheme matches modern bright office interior design | |
| Shared co-working spaces | Lockable storage secures personal items for rotating desk users | |
| Administrative department areas | Integrated CPU compartment and desk surface supports desktop computer setups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for commercial furniture | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional, safety and stability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for desk products covering load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural performance | |
|---|---|---|
| GB/T 3327-2016 | Office furniture general specification, applies to dimensional and safety requirements | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural performance; 2. GB/T 3327-2016: Office furniture general specification, applies to dimensional and safety requirements; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
