PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended users	4 persons
Distributed work-surface load	120 kg total
Single work-zone load	30 kg
Pedestal drawer load	15 kg per drawer
Lower cabinet shelf load	20 kg
Product net weight	165 kg
Chair weight capacity	120 kg per chair
Drawer operating cycles	50,000 cycles
Five-star chair base static-load target	500 kg
Top Static Load Reference	150 kg uniformly distributed

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	25 mm melamine-faced particleboard panel with sealed impact-resistant edgeband
Pedestal carcass	18 mm melamine-faced engineered-wood panels with matching woodgrain front and light-gray side trims
Support frame	Powder-coated silver steel beam and round center leg with leveling feet
Divider screen	Fabric-upholstered panel over an engineered board or acoustic core with teal face and gray lower band
Drawer hardware	Side-mounted ball-bearing drawer slides with recessed pull and central lock housing
Task chair seating	Black molded back frame, upholstered seat and back pad, black gas lift, five-star nylon or steel base and twin-wheel casters

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Workstation layout	Four individual work zones are arranged face-to-face in two bench rows, with a central divider separating opposite users
Storage organization	Each outer user position has one shallow top drawer and one lower lockable storage compartment for files and personal items
Privacy division	Two low upholstered screens provide rear/opposite-seat visual separation while retaining sightlines across the office
Cable management	The rear horizontal rail supports desk-mounted power/data modules and concealed horizontal cable routing

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office	Suited to 4-person team neighborhoods in open offices where shared benching, low privacy screens and personal filing support daily desk work
Procurement package	Recommended for standard staff workstations, project teams and administrative departments when ordered with chairs, power modules and cable trays as a coordinated package

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Office work surface safety	EN 527:2011 and EN 527:2014 for office desk safety, strength and durability
Storage cabinet safety	EN 14073:2004 for safety requirements for office storage furniture
Office chair safety	EN 1335:2020 and EN 1335:2018 for office chair dimensions and safety
Fabric upholstery behavior	EN 14465:2003 for upholstery fabric performance assessment

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Desk durability	ANSI/BIFMA X2021for desk products, including load, cyclic force and stability tests
Storage durability	ANSI/BIFMA X2019for storage units, including drawers, locks, shelves and stability verification
Task chair durability	ANSI/BIFMA X2017(R2022) for office chairs, including strength, swivel, caster and gas-chair tests

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Desk safety and dimensional suitability	GB/T 3326for furniture dimensional coordination and GB/T 3324for general wooden furniture technical requirements
Formaldehyde emission	GB 18580limit for formaldehyde emission from engineered-wood components
Office chair safety	GB/T 28004or current office swivel-chair standard for stability, gas lift, strength and durability testing

Standardized tender description text

This product must meet the following technical requirements:
1. Desk safety and dimensional suitability: GB/T 3326for furniture dimensional coordination and GB/T 3324for general wooden furniture technical requirements;
2. Formaldehyde emission: GB 18580limit for formaldehyde emission from engineered-wood components;
3. Office chair safety: GB/T 28004or current office swivel-chair standard for stability, gas lift, strength and durability testing;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-4P-2400-OAK-TEAL

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-4P-2400-OAK-TEAL

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-4P-2400-OAK-TEALOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Four-Person Panel-Based Office Workstation presents a contemporary benching solution organized as four individual work zones in two face-to-face rows. A central fabric divider separates opposite users, while two low upholstered screens provide visual privacy without closing off the surrounding office. The layout balances shared structure with personal space, making it suitable for team neighborhoods that require clear separation between seats but retain open sightlines and easy collaboration. Its visual character combines an oak-toned melamine work surface, teal divider faces, gray lower bands, and a silver support frame. Black task seating complements the neutral workstation palette. Each outer user position includes an integrated mobile pedestal with a shallow top drawer and a lower lockable compartment for files and personal items. The pedestal fronts match the woodgrain finish, while light-gray side trims add a refined contrast. Construction uses 25 mm melamine-faced particleboard for the work surface, finished with a sealed impact-resistant edgeband. The pedestal carcass is made from 18 mm melamine-faced engineered-wood panels. Structural support is provided by a powder-coated silver steel beam and round center leg with leveling feet. The main support section measures 80 mm with a 2 mm metal wall, and the finished top thickness is 50 mm. Each main seat offers 680 mm high and 900 mm wide knee clearance. Practical features are designed for daily office use. The rear horizontal rail supports desk-mounted power and data modules, with concealed horizontal cable routing through an 80 mm cable opening and a cable tray depth of 120 mm. Side-mounted ball-bearing drawer slides, recessed pulls, and a central lock housing support smooth operation and secure personal storage. Rated capacities include 30 kg for a single work zone, 120 kg total distributed work-surface load, 15 kg per drawer, 20 kg for the lower cabinet shelf, and 120 kg per chair. The supplied seating uses black molded back frames, upholstered seat and back pads, black gas lifts, five-star nylon or steel bases, and twin-wheel casters. The system is well suited to open-plan offices, standard staff workstations, project teams, and administrative departments. For coordinated procurement, it is best considered together with chairs, power modules, and cable trays. Buyers should also plan for assembly, floor protection, and delivery handling based on the packaged set weight and multi-carton format.

Four-Person Panel-Based Office Workstation with Integrated Pedestals and Divider Screens Specifications
