Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 3600 x 1200 x 750 mm | |
|---|---|---|
| Per-user work surface width | 1200 mm | |
| Per-side work surface depth | 600 mm | |
| Central privacy screen height above desk | 300 mm | |
| Mobile 3-drawer pedestal dimensions | 725 x 420 x 480 mm | |
| Minimum seated knee clearance height | 650 mm | |
| Worktop thickness | 25 mm | |
| PVC edge band thickness | 2 mm | |
| Steel support leg tube wall thickness | 1.8 mm | |
| Desktop cable grommet diameter | 80 mm | |
| Drawer internal usable depth | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set net weight (excluding pedestals) | 339 kg | |
|---|---|---|
| Per-workstation static worktop load | 135 kg | |
| Per-drawer static load capacity | 35 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Adjustable foot vertical adjustment range | 15 mm | |
| Recommended maximum user weight per station | 110 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm melamine-faced particleboard | |
|---|---|---|
| Edge trim | 2mm thick PVC edge banding | |
| Support frame | Powder-coated cold-rolled steel Z-cantilever legs | |
| Privacy dividers | Fabric-wrapped fiberboard panels | |
| Mobile pedestal body | 18mm MFC board with matching PVC edges | |
| Pedestal casters | 50mm diameter hard nylon swivel casters | |
| Drawer hardware | Cold-rolled steel 3-section ball bearing slides | |
| Leveling feet | Reinforced nylon with steel threaded stems | |
| Cable management channel | Powder-coated steel under-desk trunking | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 6 individual face-to-face work positions | |
|---|---|---|
| Cable management | Desktop grommets + central under-desk trunking | |
| Privacy screening | Low central dividers between opposing seats | |
| Per-user storage | Included mobile 3-drawer pedestal | |
| Floor leveling | Threaded adjustable feet on all leg bases | |
| Pedestal mobility | 4 swivel casters per storage unit | |
| Modular assembly | Knock-down connected frame design | |
| Drawer operation | Full-extension ball bearing slides | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office areas | Suits team-based departments requiring 6 adjacent work positions | |
|---|---|---|
| Startup and co-working spaces | Modular configuration supports flexible team expansion | |
| Back-office administrative departments | Provides dedicated per-user storage and cable management | |
| Call center and operations floors | Low dividers allow supervisor visibility while reducing cross-talk distraction | |
| Recommended configuration | Pair with ergonomic mid-back office chairs and monitor arms |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 15372:2016 | Furniture durability strength requirements for non-domestic storage |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3327-2017 | Technical requirements for metal furniture | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3327-2017: Technical requirements for metal furniture; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
