Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 2100 x 1800 x 750 mm | |
|---|---|---|
| Main worktop depth | 900 mm | |
| Right return cabinet dimensions | 1200 x 600 x 700 mm | |
| Worktop thickness | 25 mm | |
| Knee clearance height | 680 mm | |
| Knee clearance width | 1000 mm | |
| Desktop privacy screen height | 200 mm | |
| Privacy screen length | 1200 mm | |
| X-leg steel tube diameter | 50 mm | |
| Edge band thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Net desk weight | 85 kg | |
| Maximum recommended user weight capacity | 150 kg | |
| Surface scratch resistance rating | 2 N | |
| Product warranty | 5 years | |
| Available color options | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop | 25mm E0 grade engineered wood with light beige melamine finish | |
|---|---|---|
| Support legs | Polished chrome-plated steel X-frame with 50mm tubular section | |
| Desktop privacy screen | Silver anodized aluminum frame with frosted acrylic infill panel | |
| Return cabinet body | 18mm engineered wood with silver powder-coated metal side panels | |
| Return cabinet front panel | Textured light wood grain melamine finish matching worktop | |
| Storage cabinet edging | Rounded polished aluminum trim with soft corner profiles | |
| Cabinet lock | Brushed metal keyed cam lock for drawer security | |
| Adjustable feet | 10mm diameter nylon glides for floor leveling | |
| Drawer hardware | Cold-rolled steel full-extension ball-bearing slides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Right-side fixed return with 1 lockable drawer and open under-cabinet shelf | |
|---|---|---|
| Privacy screen function | Raised desktop divider blocks direct line of sight across desk | |
| Cable management | Rear cable routing channel under privacy screen with 80mm grommets | |
| Leveling adjustment | Nylon glides on cabinet base adjust 10mm to compensate for uneven floors | |
| Drawer operation | Full-extension drawer opens 450mm for full access to file contents | |
| Lock function | Keyed lock secures storage drawer to protect confidential documents | |
| Seated access | Central open knee bay provides unobstructed leg room for seated users | |
| Edge protection | 2mm rounded PVC edge banding prevents impact damage to worktop corners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive office use | Suitable for private manager or director offices in commercial buildings | |
|---|---|---|
| Open-plan manager workstation | Works as a semi-private workstation in open office areas with integrated privacy screen | |
| Small meeting use | Supports 2-person side meetings across the work surface | |
| Home office premium setup | Applicable for high-end home office spaces requiring commercial-grade durability | |
| Recommended configuration | Pair with ergonomic executive chair and under-desk CPU holder for full workstation setup |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and adjustment requirements, applicable to work height | |
| EN 13722:2004 | Office furniture storage units strength and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for drawer and cabinet endurance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and cabinet construction | |
|---|---|---|
| GB/T 3327-2017 | Performance standards for office desks and tables, applicable to structural load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E0 grade panel verification | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and cabinet construction; 2. GB/T 3327-2017: Performance standards for office desks and tables, applicable to structural load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E0 grade panel verification; 4. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
