Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 1600 x 1400 x 1100 mm | |
|---|---|---|
| Primary work surface height (floor to desktop) | 750 mm | |
| Seated knee clearance height (floor to modesty panel apron) | 680 mm | |
| Primary work surface width (leg end to return cabinet) | 1400 mm | |
| Primary work surface depth (user edge to privacy divider) | 700 mm | |
| Side return storage cabinet width | 400 mm | |
| Side return storage cabinet depth | 600 mm | |
| Desktop perforated privacy divider height above work surface | 300 mm | |
| Upper storage hutch cubby height above work surface | 350 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Modesty panel cable pass-through diameter | 60 mm | |
| Desk top panel thickness | 25 mm | |
| Splayed steel leg tube wall thickness | 1.5 mm | |
| Edge banding thickness on work surface | 2 mm | |
| Lower storage drawer internal height | 150 mm | |
| Finished Top Thickness | 50 mm |
Net weight / load capacity / users / durability
| Work surface static uniform load capacity | 113 kg | |
|---|---|---|
| Recommended maximum user weight capacity | 136 kg | |
| Leveling foot adjustment range | 10 mm | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Desk unit net weight | 78 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | 25mm E1-grade melamine-faced particle board | |
|---|---|---|
| Support legs | Powder-coated white steel splayed legs with rust-orange accent bracket | |
| Desktop privacy divider | Perforated brown engineered wood panel with orange mounting clips | |
| Storage cabinet and hutch panels | 18mm melamine-faced MDF with matching light beige finish | |
| Drawer and cabinet hardware | Zinc-plated steel lock core with 2 supplied keys, metal drawer slides | |
| Cable management grommets | ABS plastic round cable ports with brush inserts | |
| Cabinet base leveling feet | Nylon adjustable glide feet with steel threaded stems | |
| Modesty panel | 18mm melamine-faced engineered wood panel with cable pass-throughs | |
| Edge banding | 2mm thick PVC impact-resistant edge trim on all work surface edges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Desktop privacy divider | Fixed perforated panel mounted mid-work surface to block direct line of sight between adjacent seated staff | |
|---|---|---|
| Cable management system | Dual 60mm cable ports route power and data cables from desktop to under-desk area, eliminating surface cord clutter | |
| Lockable lower storage drawer | Key-locking drawer secures personal office items and confidential documents, supplied with 2 unique keys | |
| Splayed leg support structure | Angled A-frame steel leg distributes work surface weight evenly, eliminating cross-braces that obstruct leg movement | |
| Adjustable leveling feet | Threaded glide feet at cabinet base adjust to compensate for uneven floors, keeping work surface perfectly level | |
| Modesty panel | Fixed front panel below work surface blocks view of under-desk cabling and user legs for professional office appearance | |
| Fixed return orientation | Right-side mounted storage return creates L-shaped workflow with dedicated primary work zone and adjacent storage zone | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff workstations | Low privacy divider reduces visual distraction while maintaining open office collaboration space | |
|---|---|---|
| Small business private staff offices | Compact L-shaped footprint provides dedicated work surface and storage without excess floor space usage | |
| Startup flexible workspaces | Neutral light beige finish with warm orange accents complements modern flexible office interior design | |
| Coworking dedicated desks | Lockable drawer provides secure personal storage for members using assigned long-term workstations | |
| Home office workspaces | Integrated cable management and storage reduce clutter for professional remote work setups | |
| Corporate department work areas | Standard 750mm work height is compatible with all standard ergonomic office task chairs |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural stability testing | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office worktables dimensional safety requirements, applicable to ergonomic clearance verification | |
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to drawer and hutch load testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load and cycle durability validation | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and shelf load verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional tolerance and surface finish verification | |
|---|---|---|
| GB/T 3327-2022 | Performance requirements for office desks, applicable to load capacity and structural stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to indoor air quality acceptance | |
| GB/T 4897.3-2015 | Requirements for particle board used in furniture, applicable to substrate material verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional tolerance and surface finish verification; 2. GB/T 3327-2022: Performance requirements for office desks, applicable to load capacity and structural stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to indoor air quality acceptance; 4. GB/T 4897.3-2015: Requirements for particle board used in furniture, applicable to substrate material verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
