Automatic mm / inch conversion · Core engineering specifications
| Overall desk dimensions | 5400 x 800 x 750 mm | |
|---|---|---|
| Per-seat work surface width | 1800 mm | |
| Worktop thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Under-desk knee clearance height | 660 mm | |
| Per-seat knee clearance width | 1700 mm | |
| Steel frame wall thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Perforated modesty panel height | 450 mm | |
| Loop leg base footprint width | 80 mm | |
| Adjustable foot height adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 240 kg | |
|---|---|---|
| Distributed static worktop load per seat | 150 kg | |
| Drawer static load per pedestal drawer | 25 kg | |
| Integrated under-desk cable tray load capacity | 10 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Surface abrasion resistance | 2000 revolutions | |
| Recommended maximum user weight per position | 135 kg | |
| Warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E1-grade particleboard core | |
|---|---|---|
| Worktop surface finish | Thermally fused white melamine laminate | |
| Frame and modesty panel material | 2 mm cold-rolled steel | |
| Edge protection | 2 mm thick PVC edge banding | |
| Mobile pedestal body | 0.8 mm thick steel construction | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Pedestal casters | 50 mm diameter twin-wheel nylon casters | |
| Leveling feet | Reinforced nylon adjustable feet | |
| Cable management components | ABS plastic grommets and steel cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable routing system | Dual desktop grommets per seat + ventilated rear cable channel | |
|---|---|---|
| Modesty panel function | Perforated steel full-length panel | |
| Mobile pedestal storage | 3-drawer rolling unit fits under each work position | |
| Frame leveling system | Threaded adjustable feet on each leg assembly | |
| Modular linking capability | Intermediate steel legs connect adjacent seat sections | |
| Pedestal mobility | Swivel casters allow pedestals to be repositioned under desk | |
| Ventilation for powered equipment | Perforated modesty panel slots allow air circulation | |
| Work surface layout | Continuous flat seamless worktop across three positions | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 4 | |
|---|---|---|
| Largest shipping carton dimensions | 2800 x 850 x 120 mm | |
| Total shipping gross weight | 270 kg | |
| Total shipping volume | 0.85 CBM | |
| 20ft GP container loading quantity | 36 sets | |
| 40ft HQ container loading quantity | 88 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Supports 3 seated employees for daily administrative, design or data entry work | |
|---|---|---|
| Startup and co-working spaces | Linear modular layout adapts to flexible team size and hot-desking arrangements | |
| Shared back-office work zones | Integrated cable management reduces clutter in high-activity administrative departments | |
| Call center operations | Dedicated per-user space supports monitors, headsets and document storage for agents | |
| Temporary project team spaces | Can be reconfigured with additional linked sections for short-term project teams | |
| Small business general office use | Includes under-desk storage to eliminate need for separate bulky filing cabinets |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial use | |
|---|---|---|
| EN 527-2:2016 | Office work tables, dimensional and ergonomic clearance requirements | |
| EN 13722:2004 | Office furniture, storage mobile pedestals strength and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, covers strength, durability and stability for office desks | |
|---|---|---|
| ANSI/BIFMA X5.3-2021 | Vertical filing devices standard, applies to mobile pedestal storage units | |
| ANSI/BIFMA X5.9-2019 | Storage units standard, covers caster and drawer durability for mobile pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to worktop and storage components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applies to steel frame and modesty panels | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, static load and stability requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to worktop and storage components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applies to steel frame and modesty panels; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, static load and stability requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
