Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall unit dimensions | 2800 x 1200 x 750 mm | |
|---|---|---|
| Per-user worktop width | 1200 mm | |
| Per-user worktop depth | 600 mm | |
| Worktop thickness | 25 mm | |
| Desktop privacy screen height above worktop | 300 mm | |
| PVC edge banding thickness | 3 mm | |
| Knee clearance height under worktop | 650 mm | |
| Central pedestal storage width | 800 mm | |
| CPU compartment internal dimensions | 250 x 500 x 450 mm per bay | |
| Drawer internal usable dimensions | 350 x 500 x 150 mm per drawer | |
| Angled steel leg cross-section | 60 x 30 mm rectangular tube | |
| Cable grommet diameter | 80 mm | |
| Power module mounting height above worktop | 20 mm | |
| Adjustable levelling foot height adjustment | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static worktop load capacity | 260 kg | |
|---|---|---|
| Surface abrasion resistance rating | 2000 cycles | |
| Recommended maximum user weight per position | 136 kg | |
| Unit net weight | 160 kg | |
| Product warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop surface | 25mm E1 grade melamine-faced particleboard, light oak finish, stain and scratch resistant | |
|---|---|---|
| Desk legs and support frame | 1.5mm thick powder-coated white steel, splayed 45-degree angled design | |
| Edge protection | 3mm thick impact-resistant PVC edge banding, matched to worktop finish | |
| Privacy dividers | Fabric-covered acoustic panel with white finish, mounted on silver steel support posts | |
| Divider and leg brackets | Powder-coated olive green steel connecting brackets, secured with exposed steel fasteners | |
| Central storage cabinet carcass | 16mm melamine-faced particleboard, light oak drawer fronts with integrated recessed black handles |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Under-desk cable tray, worktop grommets, and divider-routed channels to route power/data cables away from leg space | |
|---|---|---|
| Integrated power module | Two integrated power/data socket units mounted on divider brackets, with AC power and USB charging ports for work devices | |
| Central storage configuration | Two lockable personal drawers and two open CPU compartments located under the central worktop for shared access | |
| Modular expansion capability | Bench frame supports connection to additional matching workstation units to extend open-plan desk runs |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office staff work areas | Accommodates four seated employees in a compact footprint to maximize open office space | |
|---|---|---|
| Small team collaborative zones | Connected design supports adjacent team work with dedicated personal work space per user |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables, safety and strength requirements for commercial desk structures | |
|---|---|---|
| EN 527-2:2016 | Office worktables, dimensional, strength and durability requirements for seated use | |
| EN 13986:2004+A1:2015 | Wood-based panels for construction, formaldehyde emission and structural performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance for office use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and environmental impact |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and storage carcass quality | |
|---|---|---|
| GB/T 3327-2018 | Dimensions and performance requirements for office desks and workstations | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, requires E1 grade compliance for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and storage carcass quality; 2. GB/T 3327-2018: Dimensions and performance requirements for office desks and workstations; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, requires E1 grade compliance for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
