| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Per work surface static load capacity | 159 kg | |
|---|---|---|
| Per drawer slide dynamic load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Workstation net weight | 60 kg | |
| Cable tray maximum load | 10 kg | |
| Privacy screen sound dampening rating | 15 dB | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panels | E1 grade melamine-faced MDF, scratch-resistant matte finish | |
|---|---|---|
| Support frame and legs | Powder-coated light gray steel, angled A-frame design | |
| Privacy divider | Brown fabric-wrapped fiberboard panel, solid support clips | |
| Cabinet door and drawer fronts | Matte white engineered wood, integrated recessed handles | |
| Interior shelf surfaces | Light wood tone melamine facing, matching open shelf edging | |
| Edge banding | 2mm ABS impact-resistant edging, matched to panel color | |
| Adjustable feet | Nylon anti-slip leveling feet, threaded metal inserts | |
| Hardware components | Zinc-plated steel screws and lock components, corrosion-resistant finish | |
| Locking cabinet core | Keyed cam lock for personal storage security | |
| Drawer slides | Full-extension cold-rolled steel ball-bearing slides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Dual-zone work surface | Two independent work areas separated by central privacy screen for two seated users | |
|---|---|---|
| Integrated side storage credenza | Upper open shelves plus lower lockable cabinet and pull-out file drawers | |
| Cable management access | 80mm diameter desktop cable grommet with routed under-desk cable tray | |
| Angled A-frame leg support | Open front leg design eliminates cross-braces to maximize unobstructed knee space | |
| Lockable personal storage | Keyed cam lock secures cabinet door for private document storage | |
| File drawer compatibility | Full-extension drawers configured for hanging A4, letter, and legal size files | |
| Leveling adjustment | Threaded nylon feet adjust 10mm vertically to compensate for uneven floors | |
| Modular connection design | Interlocking frame allows joining additional workstations for expanded open-office layouts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff workstations | Dual-zone layout with privacy divider supports focused two-person team work | |
|---|---|---|
| Small business administrative offices | Integrated storage reduces need for separate filing cabinets to save floor space | |
| Coworking space dedicated desks | Lockable storage provides secure personal storage for recurring members | |
| Team department work zones | Modular structure allows linking multiple units to create 4+ person work clusters | |
| Home office dual-user setup | Compact L-shape fits residential office spaces for shared remote work use | |
| Branch office standardization | Consistent light wood and white finish matches modern neutral office design schemes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance validation | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units strength and durability, applies to cabinet and drawer components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applies to load and durability testing for work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applies to drawer and cabinet hardware validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desk and cabinet components | |
|---|---|---|
| GB 18584-2001 | Indoor formaldehyde emission limit for wooden furniture, required for E1 grade panel acceptance | |
| GB/T 10357.1-1989 | Furniture mechanical performance test for desks, applies to worktop static load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desk and cabinet components; 2. GB 18584-2001: Indoor formaldehyde emission limit for wooden furniture, required for E1 grade panel acceptance; 3. GB/T 10357.1-1989: Furniture mechanical performance test for desks, applies to worktop static load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
