PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1400 × 700 × 750 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Distributed worktop static load	80 kg
Pedestal drawer load	15 kg
Lower storage compartment load	25 kg
Privacy screen lateral load	15 kg
Product net weight	48 kg
Recommended user capacity	1 person
Leveling adjustment	10 mm
Drawer slide durability	50000 cycles
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Worktop	25 mm wood-based panel with dark woodgrain melamine or laminate surface and matching edge banding
Privacy divider	Black semi-rigid panel with fabric-covered or acrylic face mounted in a silver metal rail
Leg frame	Silver powder-coated round steel tubing with splayed front legs and angled rear support plate
Pedestal carcass	Dark woodgrain laminated board with silver-grey side panel and impact-resistant edge banding
Hardware	Black combination lock, black slide-control plates, screws, and adjustable glides
Surface treatment	Matte dark woodgrain desktop with satin metallic steel frame

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Privacy and screen mounting	Rear black divider provides 350 mm visual separation and supports a raised monitor shelf on metal posts
Storage and security	Right pedestal provides a shallow 180 mm lockable top drawer and a 420 mm lower storage compartment
Seated access	The left 720 mm open bay keeps the pedestal outside the primary knee zone for side chair access
Floor leveling	Threaded glides under the steel legs and pedestal compensate up to 10 mm on uneven office floors

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Total carton volume	0.324 CBM
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office	Suited to one-person task seating where the 350 mm divider creates visual privacy without full enclosure
Manager or specialist workstation	The lockable pedestal supports confidential documents while the 1400 mm top accommodates laptop and notebook work

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-SGL-SCREEN-PED-1400

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-SGL-SCREEN-PED-1400

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-SGL-SCREEN-PED-1400Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Single Workstation with Privacy Screen and Locking Side Pedestal is a practical office desk solution for focused individual work. Its layout pairs a dark wood-grain work surface with a rear black privacy divider, creating a defined personal task area without producing a fully enclosed feel. The workstation is designed for one user, with a splayed silver steel leg frame and a side pedestal positioned away from the primary knee zone. This arrangement leaves an open left bay for seated access and supports a side chair while keeping files and personal items within reach. A raised monitor shelf can be supported on metal posts from the divider rail. The desk uses a matte dark woodgrain worktop with matching edge banding, giving it a restrained professional appearance suited to darker interior palettes. The privacy panel is a black semi-rigid divider available with a fabric-covered or acrylic face, mounted in a silver metal rail. Its rear placement provides visual separation while preserving an open sightline across the broader workspace. The frame is built from silver powder-coated round steel tubing, with splayed front legs and an angled rear support plate. The right storage pedestal uses dark woodgrain laminated board, a silver-grey side panel, and impact-resistant edge banding. Black slide-control plates, screws, a combination lock, and adjustable glides complete the visible hardware. Functionality is centered on privacy, cable management, storage, and security. The rear divider offers a 350 mm visual barrier and can support a monitor shelf, helping keep the main worktop clear. An 80 mm cable opening and 120 mm deep cable tray guide cabling from the desktop, while the pedestal provides a shallow lockable top drawer and a taller lower storage compartment. The combination lock secures documents, chargers, or personal belongings, making the desk suitable for handling confidential paperwork. Threaded glides beneath the steel legs and pedestal allow compensation on uneven office floors. This workstation is appropriate for open-plan offices, specialist seating, and manager or supervisor positions that require personal storage and a degree of visual privacy. It is also suitable for residential studies, professional home offices, and consultation-style workspaces where laptop and notebook work must coexist with organized paperwork. Procurement teams should plan around the desk’s two-part packaged configuration, assembly requirement, and net weight, while confirming delivery, lift access, and installation resources. The dark finishes and silver frame should be reviewed against existing furniture, and the fabric or acrylic screen face should be selected according to maintenance and visual preferences. Buyers should also confirm that the worktop, drawer, lower compartment, and screen load ratings match the intended equipment and storage use.
