Automatic mm / inch conversion · Core engineering specifications
| overall workstation dimensions (main wing × return wing × total height to screen top) | 1400 × 1200 × 1100 mm | |
|---|---|---|
| desktop working height (floor to top of work surface) | 750 mm | |
| main work surface depth (front edge to screen) | 600 mm | |
| return wing depth (corner to outer pedestal edge) | 500 mm | |
| desktop panel thickness | 25 mm | |
| storage pedestal dimensions (width × depth × height) | 420 × 550 × 700 mm | |
| central knee clearance opening (width × height) | 700 × 630 mm | |
| rear privacy screen dimensions (width × height) | 1200 × 350 mm | |
| open storage shelf (pedestal top compartment) internal dimensions | 380 × 400 × 120 mm | |
| shallow utility drawer (pedestal middle compartment) internal dimensions | 380 × 480 × 100 mm | |
| lower cabinet door compartment internal dimensions | 380 × 480 × 430 mm | |
| cable grommet diameter | 60 mm | |
| edge band thickness | 2 mm | |
| metal A-frame leg tube cross-section and wall thickness | 30 × 30 mm square tube, 1.5 mm wall thickness | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| net weight range (fully assembled) | 75 kg | |
|---|---|---|
| desktop static uniform load capacity | 80 kg | |
| adjustable foot height adjustment range | 10 mm | |
| surface flatness tolerance | ≤0.1 mm per 1000mm | |
| base stability deflection under rated load | ≤1.0 mm | |
| drawer slide dynamic load rating | 25 kg per drawer, 50000 open-close cycle durability | |
| cabinet door hinge cycle durability | 80000 open-close cycles with soft-close damping | |
| melamine finish abrasion resistance | ≥2000 revolutions without substrate exposure | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop work surface | E1-grade particleboard core with 2mm PVC edge banding, light neutral melamine laminate finish | |
|---|---|---|
| storage pedestal panels (side/back/structural) | 15mm thick E1-grade particleboard core, dark charcoal melamine finish | |
| pedestal drawer and door fronts | 18mm thick E1-grade particleboard, matching light neutral melamine finish | |
| left support leg assembly | Powder-coated matte dark grey steel, splayed A-frame configuration with horizontal cross-brace | |
| rear privacy divider panel face | Natural cork tackable surface with brown rigid frame | |
| drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| cabinet door hinge | Cold-rolled steel concealed soft-close hinge | |
| adjustable leveling feet | Nylon base with steel threaded stem | |
| drawer pull handle | Embedded dark grey ABS/metal label holder handle | |
| metal finish coating | Electrostatic epoxy powder coating, hardness ≥5H | |
| storage pedestal structural panels (side/back/internal dividers) | 15mm thick E1-grade particleboard core, dark charcoal matte melamine finish | |
| rear privacy divider panel | 12mm thick medium-density fiberboard frame with natural cork tackable face, brown matte frame finish | |
| cabinet door hinges | 1.2mm thick cold-rolled steel concealed soft-close hinges, nickel-plated finish | |
| steel frame finish coating | Electrostatic epoxy powder coating, hardness ≥5H, neutral salt spray resistance ≥48 hours without red rust | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| storage configuration | Fixed right-side pedestal includes 1 top open shelf, 1 middle shallow utility drawer, 1 lower closed door cabinet, providing tiered storage for stationery, documents and personal items | |
|---|---|---|
| cable management | Desk-top cable grommet with under-desk routing channel to conceal monitor and device power/data cables, positioned adjacent to rear screen | |
| worksurface layout | L-shaped corner configuration provides connected main work zone and return surface, with central unobstructed knee opening for seated task chair use | |
| privacy and notice function | Rear desk-mounted cork divider screen provides seated sightline privacy and tackable surface for pinned memos, notices and small documents | |
| leveling adjustment | Threaded adjustable feet on pedestal base allow 10mm height adjustment to compensate for uneven office floors, eliminating desk wobble | |
| structural support | Left side supported by braced splayed A-frame steel leg, right side fully supported by fixed storage pedestal, eliminating need for additional central leg and maximizing knee space | |
| drawer operation | Ball-bearing slides allow smooth full pull-out access to drawer contents, with integrated stop to prevent drawer pull-out during normal use | |
| cabinet door operation | Concealed hinge allows door to swing open 95 degrees for unobstructed access to lower storage compartment, with soft-close damping to prevent slamming | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| packaging method | Knock-down (KD) flat-pack packaging in 3 separate cartons (desktop panels + screen, steel leg + hardware kit, storage pedestal components) with protective foam corner padding and cardboard edge protection | |
|---|---|---|
| carton 1 (desktop + screen) dimensions | 1470 × 770 × 110 mm | |
| carton 2 (pedestal) dimensions | 770 × 580 × 430 mm | |
| carton 3 (hardware + leg) dimensions | 950 × 220 × 120 mm | |
| total gross shipping weight | 80 kg | |
| total shipping volume (CBM) | 0.23CBM | |
| required assembly time | 90 minutes for 2 people using standard hand tools (Phillips screwdriver, Allen key provided in kit) | |
| 20ft GP container loading quantity (fully KD) | 140units | |
| 40ft HQ container loading quantity (fully KD) | 320units | |
| 20ft GP container loading quantity (fully KD, palletized) | 140units |
Recommended spaces / users / usage modes
| open-plan office staff workstations | Suitable for 1 person per unit in open office layouts, with rear cork screen providing moderate privacy and pin-up space for task notes | |
|---|---|---|
| home office workspaces | Fits compact home office corner placement, with integrated storage reducing need for separate filing cabinets | |
| startup and co-working spaces | Modern two-tone design and functional storage suit flexible shared work areas, with quick assembly and reconfigurable KD structure | |
| administrative and clerical work areas | Shallow drawer and open shelf provide organized storage for office supplies, while large work surface supports monitor, keyboard and document processing | |
| recommended matching seating | Task chairs with seat height 520 mm to align with 750mm desk height and 630mm knee clearance | |
| available finish options reference | Light warm oak/white + dark grey/charcoal two-tone (as shown), full white, full dark grey, walnut dark wood options are standard for this workstation category |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions: specifies ergonomic desk height, clearance and surface dimension requirements for office workstations | |
|---|---|---|
| EN 527-2:2016 | Office furniture - Work tables and desks - Part 2: Mechanical safety requirements: applicable to structural stability, load capacity and safety performance of the desk | |
| EN 14372:2004 | Office furniture - Storage units - General safety requirements: applicable to the integrated storage pedestal drawer and cabinet components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products: standard for static load, stability, durability and safety testing applicable to commercial office workstations, recommended as acceptance reference | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units: standard for drawer and cabinet performance, cycle testing and load capacity applicable to the integrated fixed storage pedestal |
Standards applicable to China-market projects
| GB/T 3326-2016 | Furniture - Desks and tables - Main dimensions: specifies standard office desk height 760 mm and minimum knee clearance dimensions applicable to this workstation | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements: applicable to steel frame, metal hardware and structural metal components of this desk for strength and finish requirements | |
| GB 18580-2017 | Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: minimum E1 grade emission requirement for all wood-based desktop and cabinet panels | |
| GB/T 4897-2015 | Particleboard: applicable to particleboard core material used for desk tops and cabinet panels for physical performance requirements |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Furniture - Desks and tables - Main dimensions: specifies standard office desk height 760 mm and minimum knee clearance dimensions applicable to this workstation; 2. GB/T 3325-2017: Metal furniture general technical requirements: applicable to steel frame, metal hardware and structural metal components of this desk for strength and finish requirements; 3. GB 18580-2017: Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: minimum E1 grade emission requirement for all wood-based desktop and cabinet panels; 4. GB/T 4897-2015: Particleboard: applicable to particleboard core material used for desk tops and cabinet panels for physical performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
