| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 3600 x 600 x 750 mm | |
|---|---|---|
| Per-user workstation width | 1200 mm | |
| Desktop thickness | 25 mm | |
| Knee clearance height under desktop | 673 mm | |
| Privacy divider dimensions per position | 800 x 300 x 20 mm | |
| Storage pedestal dimensions (W x D x H) | 400 x 600 x 650 mm | |
| Open CPU bay internal width | 220 mm | |
| X-shaped end leg tube diameter | 50 mm | |
| Edge banding thickness | 2 mm | |
| Adjustable foot height adjustment range | 10 mm | |
| Cable grommet diameter | 80 mm | |
| Desktop surface usable depth per user | 600 mm | |
| Privacy divider frame metal thickness | 1.5 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Overall unit net weight | 185 kg | |
|---|---|---|
| Desktop uniform static load capacity | 120 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Cabinet door hinge cycle durability | 80000 cycles | |
| Recommended maximum user weight per position | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Standard commercial product warranty | 3 years | |
| Available finish color options | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core and finish | E1-grade MFC board with light wood-effect melamine laminate | |
|---|---|---|
| Support frame construction | 1.5mm thick powder-coated grey steel rectangular tubing | |
| End support leg | Polished chrome-plated 50mm diameter steel tube in X-shape | |
| Privacy divider panels | Semi-transparent frosted acrylic with 1.5mm brushed aluminum frame | |
| Storage pedestal door panels | Light wood-veneer MDF with rounded silver metal edge trim | |
| Storage pedestal side panels | 2mm thick powder-coated grey steel panels | |
| Pedestal internal drawer construction | 0.8mm thick galvanized steel drawer boxes with ball-bearing slides | |
| Hardware components | Zinc-alloy keyed cam locks, steel adjustable leveling feet, PVC edge banding | |
| Cable management components | ABS plastic cable grommets, powder-coated steel under-desk cable trays | |
| CPU bay interior lining | Ventilated powder-coated steel base with anti-scratch padding | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Workstation modularity | Connectable extension system for scaling to 4, 6 or 8 person linear runs | |
|---|---|---|
| Storage security | Keyed cam lock on each individual pedestal to secure stored documents and personal items | |
| CPU storage | Dedicated open ventilated bay between adjacent pedestals for full-size desktop computer towers | |
| Privacy screening | Desktop-mounted framed acrylic dividers to reduce visual distraction between adjacent seated users | |
| Cable management | Per-position desk grommets and under-desk cable trays to route power and data cords off the work surface | |
| Leveling adjustment | 10mm height-adjustable glide feet on each pedestal and leg to compensate for uneven office flooring | |
| Storage configuration | Each pedestal includes two pull-out drawers for stationery and A4/folio file storage | |
| Assembly method | Knock-down flat-pack construction with cam-lock and bolt fasteners for on-site assembly | |
| Surface maintenance | Stain-resistant melamine finish that can be cleaned with standard non-abrasive office cleaning products | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan corporate offices | Suitable for 3-person team clusters in open office layouts, balancing focus and collaboration | |
|---|---|---|
| Startup and co-working spaces | Modular scalable design supports flexible team expansion and agile workspace reconfiguration | |
| Government and administrative departments | Durable commercial-grade construction and lockable storage suitable for daily administrative work | |
| Small business team work areas | 3-person size fits small office floor plans without requiring dedicated private offices | |
| Call center and back-office operations | Integrated cable management and privacy dividers support focused computer-based work | |
| IT and design departments | Dedicated CPU bays accommodate high-performance desktop workstations for technical roles |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables and desks - Safety requirements, applicable to structural stability and edge safety | |
|---|---|---|
| EN 527-2:2016 | Office worktables and desks - Mechanical safety test methods for strength and durability | |
| EN 13986:2004+A1:2015 | Wood-based panels for construction - Formaldehyde emission classification, applicable to panel materials | |
| EN 1022:2005 | Domestic and non-domestic seating - Determination of stability, applicable for knee clearance compatibility |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for office desks and worktables, covering strength, durability and stability | |
|---|---|---|
| ANSI/BIFMA X7.1-2021 | Standard for formaldehyde and TVOC emissions from office furniture systems | |
| ANSI/BIFMA G1-2013 | Ergonomic guidelines for office furniture, covering correct desk height and clearance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktop and cabinet panel performance | |
|---|---|---|
| GB/T 3327-2016 | Performance and test methods for office desks, applicable to static load, stability and durability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1-grade board materials | |
| GB/T 4897.3-2015 | Performance requirements for particleboard (MFC) used in furniture construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktop and cabinet panel performance; 2. GB/T 3327-2016: Performance and test methods for office desks, applicable to static load, stability and durability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1-grade board materials; 4. GB/T 4897.3-2015: Performance requirements for particleboard (MFC) used in furniture construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
