Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W×D×H) | 2400 × 1200 × 750 mm | |
|---|---|---|
| Desktop privacy divider total height from floor | 1100 mm | |
| Desktop privacy divider dimensions per panel (W×H) | 1100 × 350 mm | |
| Individual user work zone width per seat | 1200 mm | |
| Individual user work surface depth | 600 mm | |
| Worktop panel thickness | 25 mm | |
| Under-desk knee clearance height (minimum) | 600 mm | |
| Under-desk knee clearance width per user | 600 mm | |
| Open CPU shelf internal dimensions (W×D×H) | 300 × 500 × 500 mm | |
| A-frame steel leg tube cross-section | 50 × 30 mm | |
| Adjustable glide height adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total product net weight range | 125 kg | |
|---|---|---|
| Worktop uniform static load capacity | 100 kg evenly distributed | |
| Recommended maximum user weight per seat (static load at work position) | 130 kg | |
| Number of supported users | 2 | |
| Surface abrasion resistance (melamine worktop) | ≥2000 rub cycles (Taber CS-10 wheel, 1kg load) | |
| Surface scratch hardness (worktop) | ≥2H pencil hardness | |
| Panel formaldehyde emission limit (recommended acceptance) | ≤0.05 mg/m³ (E0 grade) | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm thick particleboard core with light oak woodgrain melamine laminate facing, PVC edge banding | |
|---|---|---|
| Cabinet structural panels/modesty supports | 18mm thick particleboard core with dark gray matte melamine facing | |
| Drawer and cabinet door fronts | 18mm thick particleboard core with off-white matte melamine facing, brown decorative accent strip | |
| Left support leg | Powder-coated matte gray welded steel tube A-frame, with horizontal cross-brace for stability | |
| Desktop privacy dividers | 15mm thick MDF core with brown fabric edge trim and natural cork tackable front surface | |
| Drawer slides | Three-section full-extension silent ball-bearing steel slides, 45mm width | |
| Cabinet hinges | Concealed soft-close steel hinges, 110° opening angle | |
| Locks | Keyed cam locks, one per drawer and one per cabinet door, 2 keys per lock | |
| Base glides | Nylon adjustable leveling glides, 20mm diameter, black finish | |
| Cable management grommets | Plastic cable access grommets, 60mm diameter, dark gray finish | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Seated work surface | Fixed height 750 mm, aligned with standard ergonomic seated office work height for use with 450 mm seat height office chairs | |
|---|---|---|
| Privacy divider function | Tackable cork surface allows pinning notes, reminders and documents, provides visual privacy between adjacent workstations without blocking overhead light | |
| Under-desk storage (left pedestal) | 1 key-locking utility drawer, 1 key-locking personal storage cabinet, 1 open lower shelf for CPU tower or personal items | |
| Under-desk storage (right pedestal) | 2 key-locking drawers, with central open shelf between pedestals for shared cable management and CPU placement | |
| Cable management | Surface-mounted cable grommets at each work position, central open under-desk shelf allows routing of power and data cables between work positions and floor outlets | |
| Leveling adjustment | Individual nylon glides at all cabinet base points and leg foot allow 15 mm height adjustment to level the desk on uneven floor surfaces | |
| Storage locking | Keyed cam locks secure drawers and cabinet doors to protect personal belongings and office documents; separate keys for each lock or optional master key system per commercial furniture standard | |
| Assembly configuration | Knock-down assembly with cam-lock fasteners and bolted leg connections; designed for on-site assembly by two installers | |
| Lockable drawer internal dimensions (W×D×H) | 400 × 450 × 150 mm | |
| Lockable cabinet compartment internal dimensions (W×D×H) | 400 × 450 × 400 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 4 | |
|---|---|---|
| Largest carton dimensions (worktop panel) | 2450 × 650 × 80 mm | |
| Pedestal carton dimensions (each) | 700 × 550 × 700 mm | |
| Hardware/frame carton dimensions | 800 × 200 × 150 mm | |
| Total shipping gross weight range | 135 kg | |
| Total shipping volume (CBM) | 0.48CBM | |
| Assembly time (two trained installers) | 75 minutes | |
| 20ft GP container loading quantity | 65units | |
| 40ft HQ container loading quantity | 150units | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Open plan office staff workstations | Designed for two side-by-side employees in open office layouts, provides individual visual privacy via cork dividers while maintaining collaborative access | |
|---|---|---|
| Small office / startup workspaces | Compact 2.4m footprint fits small office rooms, provides integrated storage to eliminate need for separate filing cabinets | |
| School administration / teacher work areas | Tackable cork dividers support posting of reminders, schedules and student notices, lockable storage secures confidential documents | |
| Call center / back office operational areas | Durable melamine surfaces and fixed steel frame support heavy daily use, cable management keeps data and power cords organized for computer equipment | |
| Co-working space dedicated desks | Lockable personal storage provides security for co-working members using dedicated permanent desks, cork dividers allow personalization of work zones | |
| Home office dual work setup | Two-tone modern finish fits residential home office spaces, provides separate work areas for two people working from home without occupying excessive floor space |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions: specifies ergonomic work surface height, depth and clearance requirements for office desks | |
|---|---|---|
| EN 527-2:2016 | Office furniture - Work tables and desks - Part 2: Mechanical safety requirements: applies to structural stability, load capacity and safety of fixed office workstations | |
| EN 13986:2004+A1:2015 | Wood-based panels for use in construction - Characteristics, evaluation of conformity and marking: applies to formaldehyde emission and structural performance of panel components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Recommended references: BIFMA requirements |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture: applicable to panel-based office desk construction, dimensional tolerance, surface quality and structural strength requirements | |
|---|---|---|
| GB/T 3327-2021 | Office desks and tables: applicable to work surface height, stability, static load and durability requirements for fixed-height office workstations | |
| GB 18580-2017 | Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: applicable to all particleboard/MDF panel components, E1 grade emission ≤0.124mg/m³ as minimum requirement | |
| GB/T 4897.3-2003 | Particleboard - Part 3: Requirements for furniture grade particleboard: applicable to core panel material physical and mechanical performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture: applicable to panel-based office desk construction, dimensional tolerance, surface quality and structural strength requirements; 2. GB/T 3327-2021: Office desks and tables: applicable to work surface height, stability, static load and durability requirements for fixed-height office workstations; 3. GB 18580-2017: Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: applicable to all particleboard/MDF panel components, E1 grade emission ≤0.124mg/m³ as minimum requirement; 4. GB/T 4897.3-2003: Particleboard - Part 3: Requirements for furniture grade particleboard: applicable to core panel material physical and mechanical performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
