Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Desktop thickness | 38 mm | |
| Per-user work surface width | 915 mm | |
| Seated knee clearance height | 673 mm | |
| Privacy divider height above desktop | 320 mm | |
| Integrated storage pedestal dimensions | 400 x 500 x 654 mm | |
| Cable grommet diameter | 80 mm | |
| Small desktop accessory shelf diameter | 180 mm | |
| Metal cantilever leg section | 50 x 50 mm square tubular steel | |
| PVC edge banding thickness | 2 mm | |
| Under-desk cable tray clearance | 120 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static distributed load | 150 kg | |
|---|---|---|
| Per storage drawer static load | 45 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Pedestal cam lock cycle rating | 10000 lock/unlock cycles | |
| Workstation net weight | 140 kg | |
| Recommended user weight capacity per position | 136 kg | |
| Surface abrasion resistance rating | Class 33 commercial | |
| Substrate formaldehyde emission | 1.5 mg/L | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E1 grade particleboard with walnut wood-grain melamine finish | |
|---|---|---|
| Cantilever support leg | Powder-coated silver matte 50x50mm square steel tube | |
| Privacy dividers | 8mm thick frosted tinted acrylic with purple LED accent trim | |
| Storage pedestal panels | Melamine-faced engineered wood with brown lower and grey upper accent panels | |
| Door hinges | Cold-rolled steel soft-close hinges with matte black finish | |
| Desktop edge trim | 2mm thick seamless PVC edge banding, color-matched to worktop | |
| Integrated power module | Fire-resistant ABS housing with AC outlets and USB-C charging ports | |
| Adjustable pedestal feet | Reinforced nylon glides with 10mm height adjustment | |
| Accessory shelf frames | Black powder-coated steel circular raised shelf supports | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Storage security | Keyed cam locks on each pedestal, securing 2 doors per cabinet for personal file storage | |
|---|---|---|
| Cable management | 80mm desktop grommets route cables to under-desk tray, integrated power module with USB-C charging | |
| User privacy | 320mm high acrylic dividers block direct seated sightlines between adjacent workers | |
| Structure support | Dual fixed storage pedestals and one cantilever steel leg provide stable support without crossbars blocking legroom | |
| Surface utility | Two raised circular side shelves hold small items to free main work surface for computers and documents | |
| Floor protection | Adjustable nylon glides on pedestals compensate for uneven floors and prevent floor scratching | |
| Storage access | Dual-door pedestals provide enclosed vertical file storage for each workstation user | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan offices | Dual-position configuration supports two administrative or clerical staff in shared workspace | |
|---|---|---|
| Startup team workspaces | Integrated storage and charging reduces need for additional furniture in compact offices | |
| Call center stations | Privacy dividers reduce visual distraction between adjacent agents during shifts | |
| Shared administrative areas | Lockable storage secures personal documents and office supplies for each user | |
| Co-working day offices | Dual independent work positions support flexible hot-desking for two occupants | |
| Small business staff areas | Stable fixed-height design provides durable daily use for 4person teams |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial workstation use | |
|---|---|---|
| EN 14372:2004 | Office furniture storage units safety and durability requirements for pedestals | |
| EN 12521:2015 | Furniture mechanical safety requirements for structural stability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for pedestal lock and slide performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structure and finish | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, ≤0.124mg/m³ for E1 grade acceptance | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to desktop substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structure and finish; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, ≤0.124mg/m³ for E1 grade acceptance; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to desktop substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
