Automatic mm / inch conversion · Core engineering specifications
| Overall cluster dimensions (worksurface only) | 3600 x 1200 x 750 mm | |
|---|---|---|
| Overall height including privacy dividers | 1100 mm | |
| Per-seat worksurface width | 1200 mm | |
| Per-seat worksurface depth | 600 mm per side, 1200mm total across paired seats | |
| Seated knee clearance height | 620 mm | |
| Knee clearance width per position | 580 mm | |
| Worksurface thickness | 25 mm | |
| Storage pedestal dimensions | 725 x 420 x 480 mm | |
| Drawer front panel thickness | 16 mm | |
| PVC edge banding thickness | 2 mm | |
| Privacy divider height above worksurface | 350 mm | |
| Cable grommet diameter | 80 mm | |
| Metal leg wall thickness | 1.8 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Total product net weight | 260 kg | |
|---|---|---|
| Worksurface static load capacity per seat | 100 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door/cabinet hinge cycle rating | 80000 cycles | |
| Recommended maximum user weight per seat | 120 kg | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface substrate | E1 grade particleboard core with light wood grain melamine laminate | |
|---|---|---|
| Worksurface edge protection | 2mm thick PVC edge banding, impact resistant | |
| Support frame and legs | White powder-coated thickened steel, angled leg design | |
| Storage pedestal panels | 16mm thick melamine-faced MFC board, light wood grain match | |
| Privacy divider surfaces | Terracotta-colored fabric wrapped over MDF core | |
| Drawer and cabinet hardware | Cold-rolled steel drawer slides, keyed cam locks, metal handles | |
| CPU storage bay panels | Matching melamine laminate panels with open access slot | |
| Cable management components | ABS plastic grommets, under-desk steel cable trays | |
| Foot pads | Adjustable nylon leveling glides on all leg and pedestal bases | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Modular configuration | Pre-configured 6-person face-to-face linear cluster, compatible with expansion modules | |
|---|---|---|
| Integrated storage per seat | 2-drawer lockable pedestal per position, dedicated open CPU storage bay under worksurface | |
| Privacy separation | Low terracotta fabric dividers between opposite seated users, reducing direct visual distraction | |
| Cable management | Desktop cable grommets at each position route cords to under-desk trays, eliminating tangles | |
| Leveling adjustment | Adjustable nylon feet on all legs and pedestals compensate for uneven concrete office floors | |
| Drawer security | Keyed lock on each pedestal secures both drawers for personal document and supply storage | |
| Assembly design | Knock-down flat-pack construction with shared support legs between adjacent work positions | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan corporate office staff areas | Supports 6 employees in a compact footprint, suited for general admin and operational teams | |
|---|---|---|
| Co-working space dedicated team zones | Modular design allows reconfiguration as team sizes change, with built-in personal storage | |
| Start-up office open work areas | Cost-effective cluster layout maximizes space efficiency without dedicated full cubicle partitions | |
| Back-office administrative departments | Integrated drawers and CPU storage keep work surfaces clear for daily paperwork and computer tasks | |
| Call center work floors | Low privacy dividers reduce distraction while maintaining supervisor visibility across the cluster |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural load testing | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional and ergonomic requirements, applicable to knee clearance and height | |
| EN 13722:2004 | Office furniture storage units performance requirements, applicable to drawer and cabinet durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural safety, load capacity, and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer cycle and load performance validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worksurface and cabinet panel quality | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks and workstations, applicable to structural stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade substrate compliance | |
| GB/T 4897.3-2015 | Particleboard specifications for furniture use, applicable to worksurface substrate quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worksurface and cabinet panel quality; 2. GB/T 3327-2016: Performance requirements for office desks and workstations, applicable to structural stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade substrate compliance; 4. GB/T 4897.3-2015: Particleboard specifications for furniture use, applicable to worksurface substrate quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
