Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 mm W × 1200 mm D × 1050 mm H | |
|---|---|---|
| Seated worksurface height | 750 mm | |
| Per-user worksurface area | 1200 mm W × 600 mm D | |
| Cork privacy divider dimensions | 1150 mm W × 300 mm H × 12 mm T (per divider, 2 units total) | |
| Worksurface panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Central storage pedestal dimensions | 1200 mm W × 600 mm D × 720 mm H | |
| Per-side knee clearance opening | 580 mm W × 600 mm D × 700 mm H | |
| Drawer internal dimensions (upper stationery drawer) | 400 mm W × 500 mm D × 150 mm H | |
| Drawer internal dimensions (lower file drawer) | 400 mm W × 500 mm D × 300 mm H | |
| Steel A-frame leg section | 50 mm × 30 mm rectangular tube, 1.5 mm wall thickness | |
| Cross-brace bar diameter | 20 mm round steel tube | |
| Leveling foot adjustment height | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Per-worksurface static uniform load capacity | 100 kg | |
|---|---|---|
| Drawer slide operation cycle rating | 50000 open/close cycles | |
| Product net weight range | 155 kg | |
| Worksurface surface abrasion resistance | ≥2000 revolutions (Taber CS-10 wheel, 1kg load) | |
| Recommended maximum user weight per workstation | 130 kg | |
| Surface heat resistance | 120 °C short-term contact | |
| Worksurface surface stain resistance | Resistant to common office liquid spills (coffee, tea, ink, water) with 24-hour spill cleaning window | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface panel | E1 grade melamine-faced particleboard, light matte off-white finish | |
|---|---|---|
| Edge banding | 2mm thick matching-color PVC, hot-melt adhesive applied with automatic edge banding process | |
| Leg and frame structure | 1.5mm wall thickness powder-coated dark gray steel rectangular tube, splayed A-frame design with round steel cross-bracing | |
| Central storage pedestal carcase | 18mm thick dark gray melamine-faced particleboard | |
| Drawer fronts | 18mm thick light beige melamine-faced particleboard with integrated recessed pull handle | |
| Privacy divider panels | 12mm thick agglomerated cork facing with dark brown MDF edge frame, pin-receptive surface | |
| Drawer hardware | 3-section full-extension ball bearing steel slides, integrated drawer lock on upper drawer | |
| Leveling feet | Nylon base with steel threaded stem, adjustable height | |
| Divider mounting brackets | Powder-coated steel mounting clips securing dividers to worksurface center | |
| Base glides on central pedestal | Small nylon floor glides at each pedestal corner | |
| Central pedestal back panel | 3mm thick hardboard backing for cabinet structural rigidity | |
| Drawer interior panels | 16mm thick melamine-faced particleboard, matching carcase color | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Workstation layout | Face-to-face configuration with 4 dedicated seated work positions (2 users per long side) | |
|---|---|---|
| Cork privacy dividers | Central mounted panels provide visual privacy between opposite-facing users, with pinable cork surface for posting notes, memos or photos | |
| Central storage configuration | Shared central pedestal includes 2 lockable drawers per side (1 upper stationery drawer, 1 lower hanging file drawer) for adjacent workstation user storage | |
| Frame stability | Splayed A-frame outer legs with horizontal cross-bracing eliminate side-to-side frame wobble during regular office use | |
| Floor leveling | Adjustable nylon feet on each leg end allow fine height adjustment to level the desk on uneven office flooring, with non-marking surface to protect hard floors | |
| Surface function | Matte non-glare worksurface reduces screen glare from monitors and overhead office lighting, with smooth stain-resistant finish for easy cleaning | |
| Modular expandability | Bench design supports connection of additional matching desk units to extend the workstation run in open plan offices | |
| Drawer locking | Upper drawer per pedestal side includes a keyed lock to secure personal stationery and confidential documents; lower file drawer locks simultaneously with upper drawer via linked mechanism | |
| Optional cable management | Field-installable 80mm diameter desk grommets and under-desk steel cable trays (15kg load capacity) can be added to route power and data cords for monitors and office equipment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 6 cartons | |
|---|---|---|
| Largest carton dimensions | 2450 mm × 650 mm × 80 mm (worktop panels) | |
| Total shipping gross weight | 170 kg | |
| Total shipping volume (CBM) | 0.55CBM | |
| Required on-site assembly time | 90 minutes for 2 trained installers | |
| Full 40ft HQ container loading quantity | 110units | |
| Minimum order quantity | 5 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
Recommended spaces / users / usage modes
| Open plan office work areas | Suitable for 4-person team clusters in open plan corporate offices, providing divided personal work space with adjacent shared storage | |
|---|---|---|
| Startup and co-working spaces | Ideal for flexible co-working facilities and startup offices, with modular expandability to reconfigure team seating as needed | |
| Administrative and departmental work zones | Suitable for administrative staff, accounting, and customer service team areas with frequent document storage needs | |
| Project team workspaces | Supports small project teams working face-to-face, with partial visual separation from cork dividers while maintaining easy team communication | |
| Recommended matching furniture | Pair with mid-back ergonomic office chairs with seat height 520 mm to match 750mm worksurface height, and under-desk cable management trays for power and data wiring | |
| Not suitable for uses | Not designed for standing height work, heavy industrial equipment placement, or outdoor use due to wood-based panel and powder-coated steel construction | |
| Training room temporary seating | Not recommended for high-turnover training room use due to fixed storage pedestal and lack of reconfigurable mobility; suitable for permanent assigned seating only |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions, specifying standard seated desk height (760 mm), worksurface depth and leg clearance requirements | |
|---|---|---|
| EN 527-2:2002+A1:2006 | Office furniture - Work tables and desks - Part 2: Mechanical safety requirements, specifying stability, strength and durability test methods for work surfaces and storage components | |
| EN 13722:2004 | Office furniture - Storage units, specifying mechanical safety and performance requirements for drawer units including drawer load capacity and cycle testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests, specifying static load, impact, cycle and stability test methods for office work surfaces, drawer units and frame structures | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units, specifying cycle testing, load capacity and safety requirements for free-standing and integrated under-desk storage pedestals | |
| ANSI/BIFMA e3-2019 | Furniture Sustainability Standard, applicable for projects requiring low-VOC material and sustainable manufacturing criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood-based panel worktops and cabinet components, specifying dimensional tolerance, moisture content (12%), and structural strength requirements | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable to powder-coated steel frame and leg components, specifying coating adhesion, weld quality, and structural stability requirements | |
| GB 18580-2017 | Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels and finishing products, applicable to particleboard components requiring E1 grade (≤0.124mg/m³) formaldehyde emission | |
| GB/T 4897.3-2015 | Particleboard - Part 3: Requirements for particleboard for furniture use, specifying board density, internal bond strength, and screw holding force for worktop and cabinet panels | |
| GB/T 24821-2009 | Office furniture - Office work desks and chairs, specifying dimensional, safety and performance requirements for commercial office desk products | |
| Powder coating adhesion rating | Grade 0 (cross-cut test, GB/T 9286) |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood-based panel worktops and cabinet components, specifying dimensional tolerance, moisture content (12%), and structural strength requirements; 2. GB/T 3325-2017: General technical requirements for metal furniture, applicable to powder-coated steel frame and leg components, specifying coating adhesion, weld quality, and structural stability requirements; 3. GB 18580-2017: Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels and finishing products, applicable to particleboard components requiring E1 grade (≤0.124mg/m³) formaldehyde emission; 4. GB/T 4897.3-2015: Particleboard - Part 3: Requirements for particleboard for furniture use, specifying board density, internal bond strength, and screw holding force for worktop and cabinet panels; 5. GB/T 24821-2009: Office furniture - Office work desks and chairs, specifying dimensional, safety and performance requirements for commercial office desk products; 6. Powder coating adhesion rating: Grade 0 (cross-cut test, GB/T 9286); Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
