Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1200 x 1100 mm | |
|---|---|---|
| Worksurface height | 750 mm | |
| Per-user worktop width | 1200 mm | |
| Per-side worktop depth | 600 mm | |
| Desktop panel thickness | 25 mm | |
| PVC edge band thickness | 2 mm | |
| Privacy divider height above worktop | 350 mm | |
| Knee clearance height under worktop | 650 mm | |
| Integrated storage pedestal width per unit | 600 mm | |
| Cable grommet diameter | 80 mm | |
| Square support steel leg section | 60 x 60 mm | |
| Steel frame wall thickness | 1.2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop concentrated static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle durability | 50000 cycles | |
| Hinge open/close cycle durability | 80000 cycles | |
| Worksurface abrasion resistance rating | 2000 cycles | |
| Product net weight reference | 85 kg | |
| Recommended maximum user weight per seat | 120 kg | |
| Available finish color options | 12 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E1-grade particleboard | |
|---|---|---|
| Worktop surface finish | Melamine laminate | |
| Edge banding | 2mm thick PVC matching trim color | |
| Support frame and legs | Powder-coated square steel tube | |
| Privacy dividers | MDF panel with brown melamine finish | |
| Storage pedestal cabinet bodies | 18mm thick melamine-faced particleboard | |
| Drawer and door hardware | Zinc alloy lock cores, steel slide rails | |
| Cable management components | ABS plastic grommets and cable channels | |
| Leveling feet | Reinforced nylon with threaded steel insert | |
| Modesty panels | 18mm thick melamine-faced particleboard | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 4 face-to-face seated work positions | |
|---|---|---|
| Privacy divider function | Blocks direct line of sight between opposite seated users | |
| Storage per workstation | 1 lockable top drawer + 1 lockable door cabinet | |
| Cable management system | Dual circular grommets per pedestal + under-desk routing trays | |
| Structural support | Mixed cantilever steel leg + storage pedestal base support | |
| Leveling adjustment | Threaded adjustable feet on all base contact points | |
| Cable access cutouts | Recessed cable channels below privacy dividers | |
| Drawer operation | Full-extension ball-bearing drawer slides | |
| Cabinet door operation | 110-degree open-swing hinged doors | |
| Modular expansion | Compatible with adjacent benching units | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff zones | Supports 4 concurrent employees for general administrative and task work | |
|---|---|---|
| Startup and co-working spaces | Flexible modular configuration adapts to growing team sizes | |
| Call center and back-office operations | Privacy dividers reduce visual distraction between adjacent agents | |
| Corporate departmental work areas | Two-tone neutral finish coordinates with most modern office interior schemes | |
| Temporary project team spaces | Reconfigurable benching can be disassembled and relocated as team needs change | |
| Small business office layouts | All-in-one workstation eliminates need for separate desks, screens and storage pedestals |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to worksurface and frame performance | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety requirements for non-domestic seating-adjacent desks | |
| EN 13986:2004+A1:2015 | Wood-based panels for structural use, applicable to worktop and divider panel material specifications |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to static load and durability testing | |
|---|---|---|
| ANSI/BIFMA G1-2013 | Ergonomic guidelines for office furniture, applicable to worksurface height and clearance dimensions |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worktop and cabinet components | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to particleboard and MDF substrates | |
| GB/T 10357.1-2013 | Desk strength and stability test methods, applicable to structural load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worktop and cabinet components; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to particleboard and MDF substrates; 3. GB/T 10357.1-2013: Desk strength and stability test methods, applicable to structural load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
