Single-Sided Workstation Desk with Dark Divider Screen and Right Storage Pedestal (model WS-DRK-1600-RP-SCREEN) is listed under Open Workstation. Dimensions: 1600 × 700 × 1100 mm. Materials: 25 mm wood-composite panel with dark wood-grain laminate surface and matching edge banding. Load capacity: 80 kg. Product Features: modern,style,single,workstation,right,pedestal,storage,desktop,privacy,screen,metal,frame. This page consolidates 6 groups of specifications and ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | XIANGSHI | Model | WS-DRK-1600-RP-SCREEN |
| Overall dimensions (W × D × H) | 1600 × 700 × 1100 mm | Overall desk footprint | 1600 x 700 x 1100 mm including divider screen |
| Finished Top Thickness | 50 mm | Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
| Distributed desktop static load | 80 kg | Pedestal drawer load per drawer | 15 kg |
| Open shelf load | 12 kg | Recommended user capacity | 1 person |
| Chair and knee-space compatibility | Swivel chair seat width up to 520 mm | Net weight reference | 58 kg |
| Pedestal lock security | 1 keyed lock position | Hardware cycle target | Drawer slides rated for 50,000 opening cycles |
| Floor load concentration | 120 kg maximum localized load | Top Static Load Reference | 150 kg uniformly distributed |
| Worktop substrate and finish | 25 mm wood-composite panel with dark wood-grain laminate surface and matching edge banding | Pedestal panels | 18 mm graphite-gray wood-composite panels with matte melamine or laminate facing |
| Support frame | Powder-coated steel or die-cast aluminum-looking angled legs with twin splayed feet | Divider panel | Dark matte fabric-faced board or tinted acrylic panel in a slim framed rail |
| Mounting rail and screen brackets | Dark metal rail with two triangular desktop brackets | Drawer lock | Round key lock with black insert and metallic outer ring |
| Privacy divider function | Low rear screen blocks direct sight lines while maintaining overhead visibility and open-office air flow | Storage configuration | Right pedestal combines one upper lockable drawer, one lower large drawer or door, and one open side shelf |
| Cable management provision | Desktop oval cable port accepts monitor and power leads, with routing toward rear pedestal zone | Pedestal support function | Right cabinet doubles as storage and torsional support, while the left splayed frame resists side racking |
| Flat-pack carton dimensions | 1680 x 760 x 120 mm for top pack; 720 x 620 x 420 mm for pedestal pack; 820 x 420 x 180 mm for frame pack | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | Reference Packaging Volume | 1 m³/set |
| Manager or supervisor desk | Fits private offices and compact management rooms needing laptop work, locked personal storage and a structured modern appearance | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 700 × 1100 mm | |
|---|---|---|
| Overall desk footprint | 1600 x 700 x 1100 mm including divider screen | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed desktop static load | 80 kg | |
|---|---|---|
| Pedestal drawer load per drawer | 15 kg | |
| Open shelf load | 12 kg | |
| Recommended user capacity | 1 person | |
| Chair and knee-space compatibility | Swivel chair seat width up to 520 mm | |
| Net weight reference | 58 kg | |
| Pedestal lock security | 1 keyed lock position | |
| Hardware cycle target | Drawer slides rated for 50,000 opening cycles | |
| Floor load concentration | 120 kg maximum localized load | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop substrate and finish | 25 mm wood-composite panel with dark wood-grain laminate surface and matching edge banding | |
|---|---|---|
| Pedestal panels | 18 mm graphite-gray wood-composite panels with matte melamine or laminate facing | |
| Support frame | Powder-coated steel or die-cast aluminum-looking angled legs with twin splayed feet | |
| Divider panel | Dark matte fabric-faced board or tinted acrylic panel in a slim framed rail | |
| Mounting rail and screen brackets | Dark metal rail with two triangular desktop brackets | |
| Drawer lock | Round key lock with black insert and metallic outer ring |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Privacy divider function | Low rear screen blocks direct sight lines while maintaining overhead visibility and open-office air flow | |
|---|---|---|
| Storage configuration | Right pedestal combines one upper lockable drawer, one lower large drawer or door, and one open side shelf | |
| Cable management provision | Desktop oval cable port accepts monitor and power leads, with routing toward rear pedestal zone | |
| Pedestal support function | Right cabinet doubles as storage and torsional support, while the left splayed frame resists side racking |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Flat-pack carton dimensions | 1680 x 760 x 120 mm for top pack; 720 x 620 x 420 mm for pedestal pack; 820 x 420 x 180 mm for frame pack | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Manager or supervisor desk | Fits private offices and compact management rooms needing laptop work, locked personal storage and a structured modern appearance |
|---|
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
