Primary source
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 1400 × 750 mm | |
|---|---|---|
| Per-user worktop area | 1200 x 700 mm | |
| Worktop thickness | 25 mm | |
| Central privacy divider height | 300 mm | |
| Under-desk knee clearance height | 673 mm | |
| Fixed storage pedestal dimensions | 406 x 498 x 660 mm | |
| PVC edge banding thickness | 2 mm | |
| Metal frame tube section | 60 x 30 mm | |
| Cable grommet diameter | 80 mm | |
| CPU compartment dimensions | 250 x 500 x 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Worktop static load capacity per user | 100 kg | |
|---|---|---|
| Drawer slide cycle life | 50000 cycles | |
| Frame wall thickness | 1.2 mm | |
| Total unit net weight | 130 kg | |
| Surface heat resistance | 120 °C | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop surface | E1-grade melamine laminated particleboard with light oak woodgrain finish | |
|---|---|---|
| Edge protection | 2 mm thick PVC edge banding sealed to all worktop and panel edges | |
| Support frame | White powder-coated 1.2 mm thick rectangular steel tube, angled cantilever legs | |
| Central privacy screen | Sage green fabric-upholstered composite board divider | |
| Pedestal drawer fronts | Sage green melamine-faced particleboard with integrated metal pulls | |
| Pedestal cabinet body | Light oak-effect melamine laminated particleboard, floor-supported base | |
| Adjustable feet | Nylon floor levellers with 10 mm adjustment travel | |
| Cable management hardware | ABS plastic cable grommets and under-desk steel cable tray | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating layout | Face-to-face dual-seat configuration with central divider separating two work positions | |
|---|---|---|
| Per-user storage | One fixed floor-standing pedestal per seat with 1 upper drawer and 1 lower cabinet door | |
| CPU storage | Dedicated open under-desk compartment between pedestal and frame for full-size desktop towers | |
| Cable routing | Integrated desk grommets and under-desk cable tray to route power and data cables out of sight | |
| Floor leveling | Adjustable nylon feet on frame and pedestal bases to compensate for uneven floor surfaces | |
| Privacy separation | Low central fabric divider blocks direct line of sight between facing users at seated height | |
| Modular connectivity | Pre-drilled frame connection points to link additional workstations for larger open-plan layouts | |
| Surface durability | Scratch and stain-resistant melamine finish suitable for daily office equipment and supply use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office staff areas | Designed for two employees per unit in high-density corporate open-plan work zones | |
|---|---|---|
| Small office and startup spaces | Compact footprint with integrated storage reduces need for separate filing furniture | |
| Home office dual-workstation setups | Neutral light oak and sage green finish suits residential office aesthetics | |
| Hot-desking environments | Durable melamine surfaces and standard dimensions suit shared daily use by rotating staff | |
| Project team zones | Face-to-face layout supports easy collaboration between paired team members |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables – Part 1: Dimensions, applicable to seated work surface height and clearance | |
|---|---|---|
| EN 527-2:2016 | Office work tables – Part 2: Mechanical safety requirements, applicable to structural stability | |
| EN 1335-1:2020 | Office work chair dimensions, for reference when pairing with compatible task seating |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products – Tests for structural performance and durability, recommended for commercial procurement validation | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units – Performance requirements for integrated pedestal drawers and cabinets |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminated panel desk components | |
|---|---|---|
| GB/T 3327-2016 | Performance and test methods for office desks, applicable to worktop and frame structural requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1-grade board selection |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminated panel desk components; 2. GB/T 3327-2016: Performance and test methods for office desks, applicable to worktop and frame structural requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1-grade board selection; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
