Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (3-seat linear cluster) | 4500 x 700 x 750 mm (work surface height) | |
|---|---|---|
| Individual work surface size per seat | 1500 x 700 mm | |
| Seated knee clearance height under work surface | 650 mm | |
| Seated knee clearance depth at leg opening | 450 mm | |
| Desktop privacy divider height above work surface | 350 mm | |
| Privacy divider panel thickness | 30 mm | |
| Integrated pedestal unit dimensions | 400 x 600 x 650 mm per unit | |
| Drawer internal usable dimensions per drawer | 320 x 500 x 120 mm | |
| Lower open storage shelf internal dimensions | 350 x 550 x 250 mm | |
| Work surface panel thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Angled end support leg cross-section size | 60 x 30 mm | |
| Cable grommet diameter per work position | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Static load capacity per individual work surface | 150 kg | |
|---|---|---|
| Recommended number of users per workstation cluster | 3 | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Melamine surface abrasion resistance rating | 2000 cycles | |
| Total product net weight (3-seat unit) | 150 kg | |
| Commercial hardware warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | E1 grade particleboard with light oak-effect melamine laminate, 2mm PVC edge banding, 30° beveled edges | |
|---|---|---|
| Support legs and frame | 1.5mm thick powder-coated steel, white finish, angled splayed design at open ends | |
| Desktop privacy dividers | 30mm thick MDF core with sage green matte fabric wrap, angled top edge | |
| Storage pedestal body panels | 18mm thick white melamine-laminated particleboard, PVC edge banding | |
| Drawer fronts | 18mm thick sage green melamine-laminated MDF, integrated recessed pull handles | |
| Drawer hardware | Cold-rolled steel soft-close full-extension runners, optional keyed locking core per drawer | |
| Leveling feet at pedestal base | 10mm diameter nylon adjustable glides, 15mm vertical adjustment range | |
| Cable management components | ABS plastic cable grommets, 0.8mm thick steel under-desk cable tray | |
| Open shelf base panel | 18mm thick white melamine-laminated particleboard, reinforced with steel corner brackets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Full-extension soft-close runners, drawers pull fully out with no harsh closing slam | |
|---|---|---|
| Cable management | 60mm diameter desk grommets at each work position route power/data cables to under-desk trays | |
| Privacy separation | 350mm high fabric dividers block direct line of sight between adjacent seated users | |
| Integrated storage configuration | Two drawers per pedestal for small supplies/items plus one lower open shelf per position | |
| Floor leveling adjustment | Nylon glides at pedestal bases adjust up to 15mm vertically | |
| Modular expansion capability | Cam-lock bolted KD connection points allow linking additional identical workstation units | |
| Seating compatibility | 650mm high knee clearance accommodates standard ergonomic office chairs with 520 mm seat height | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons per 3-person workstation | 6 cartons | |
|---|---|---|
| Largest shipping carton dimensions | 1600 x 800 x 120 mm | |
| Total packaged gross weight per unit | 150 kg | |
| Total packaged volume per unit | 0.8 CBM | |
| Required assembly time for 2-person installation team | 50 minutes | |
| 40ft HQ container loading quantity | 85 sets | |
| Packaging protection materials | 5-ply corrugated carton, 20mm PE foam lining, hard corner protectors, sealed hardware kit | |
| Included spare parts allowance | 5% extra cam locks, bolts and glides included per unit | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Open plan corporate office staff areas | Linear 3-seat cluster fits row layouts for admin, sales or operations teams | |
|---|---|---|
| Co-working space open seating zones | Neutral light wood and sage finish fits modern flexible work environments | |
| Startup office team work areas | Modular expandable design scales as headcount grows without full furniture replacement | |
| Government or institutional back-office areas | Commercial-grade durable construction withstands daily high-traffic long-term use | |
| Call center and shared service team floors | Low dividers enable supervisor visibility while reducing cross-talk distraction | |
| Educational institution staff workrooms | Durable laminate surfaces resist spills and heavy daily use by teaching and admin staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables – Part 1: Dimensions, applicable to work surface height and clearance | |
|---|---|---|
| EN 527-2:2018 | Office work tables – Part 2: Mechanical safety and stability requirements | |
| EN 13722:2004 | Furniture – Strength and durability of storage units, applicable to integrated pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Furniture - Desk Products standard, applicable to structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard, applicable to integrated drawer pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminated panel desk construction | |
|---|---|---|
| GB/T 3327-2017 | Performance standards for office desks and workstations, applicable to work surface load, stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panel products, applicable to E1 grade panel materials | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable to melamine laminate tops |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminated panel desk construction; 2. GB/T 3327-2017: Performance standards for office desks and workstations, applicable to work surface load, stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panel products, applicable to E1 grade panel materials; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable to melamine laminate tops; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
