Two-Person Double Office Bench Workstation with Central Privacy Divider and Mobile 3-Drawer Pedestal (model OFB-2P-TER-DIV-MP3) is listed under Open Workstation, with overall dimensions of 1676 × 1245 × 762 mm and main material of Particle‑board (PB). Load capacity: 150 kg. Certifications: modern,open-plan,design,double-seat,bench,configuration,mobile,under-desk,storage,desk-mounted,privacy,screen. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation dimensions | 1676 x 1245 x 762 mm | |
|---|---|---|
| Per-user work surface dimensions | 1521 x 610 mm | |
| Desktop thickness | 25 mm | |
| PVC edge banding thickness | 3 mm | |
| Cylindrical steel leg diameter | 50 mm | |
| Desk-mounted privacy panel dimensions | 1499 x 350 mm | |
| Under-desk knee clearance height | 673 mm | |
| Mobile 3-drawer pedestal dimensions | 400 x 550 x 654 mm | |
| Cable grommet diameter | 76 mm | |
| Caster wheel diameter | 50 mm | |
| Leveling foot adjustment range | 10 mm | |
| Copper-colored leg corner cap thickness | 3 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed desktop static load capacity | 150 kg | |
|---|---|---|
| Workstation seated user capacity | 2 users | |
| Drawer slide cycle durability | 50000 cycles | |
| Surface scratch resistance rating | Class 2 | |
| Total workstation net weight | 145 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm thermally fused melamine laminated particleboard | |
|---|---|---|
| Support legs | Powder-coated cylindrical steel with decorative copper accent caps at joints | |
| Central privacy divider | Fabric-wrapped acoustic panel in terracotta finish | |
| Mobile pedestal body | Powder-coated steel with white finish, dark grey laminate top | |
| Pedestal hardware | Full-extension ball bearing drawer slides, 5 swivel casters (2 locking) | |
| Cable management components | ABS plastic cable grommets with removable caps |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Privacy divider function | Central desk-mounted screen separates two adjacent work zones to reduce visual distraction | |
|---|---|---|
| Mobile pedestal function | Under-desk rolling storage with 2 box drawers and 1 hanging file drawer, central key lock secures all drawers | |
| Cable management function | Desk-top grommets route power and data cables from work surface to under-desk area | |
| Leveling function | Adjustable glides on each leg compensate for uneven floor surfaces up to 10mm |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total carton count | 5 cartons | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office work zones | Double-seat configuration fits standard 1.8m bay spacing for team collaboration areas | |
|---|---|---|
| Small business shared workspaces | Compact footprint includes integrated privacy and storage for startup or co-working environments |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and dimensional requirements | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables, mechanical safety and strength test methods | |
| EN 1335-1:2020 | Office furniture reference for seating clearance compatibility |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for performance, durability, and structural safety | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard applicable to mobile pedestal performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminated work surfaces | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and pedestal | |
| GB 28007-2011 | Office furniture desk and table strength and durability test methods |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminated work surfaces; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and pedestal; 3. GB 28007-2011: Office furniture desk and table strength and durability test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
