Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1400 x 700 x 750 mm | |
|---|---|---|
| worktop thickness | 25 mm | |
| ABS edge banding thickness | 2 mm | |
| privacy divider height above worktop | 300 mm | |
| knee clearance height under worktop | 720 mm | |
| knee clearance width under open leg side | 800 mm | |
| pedestal storage width | 400 mm | |
| pedestal open cubby internal height | 200 mm | |
| drawer internal usable depth | 350 mm | |
| angled steel leg section size | 50 x 30 mm | |
| adjustable leveler foot height adjustment | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| worktop static uniform load capacity | 100 kg | |
|---|---|---|
| open storage cubby maximum static load | 15 kg | |
| unit net weight | 52 kg | |
| surface scratch resistance rating | 2000 cycles | |
| drawer slide operational cycle rating | 50000 cycles | |
| maximum recommended user weight for seated use | 136 kg | |
| available standard finish color count | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| worktop substrate | 18 mm particleboard core with melamine facing | |
|---|---|---|
| pedestal cabinet body | 15 mm melamine-faced engineered wood | |
| support legs | 1.2 mm thick powder-coated white steel | |
| edge protection | 2 mm thick ABS edge banding | |
| privacy divider core | 12 mm medium density fiberboard with sage green fabric wrap | |
| drawer slides | Cold-rolled steel 3/4 extension ball bearing slides | |
| leveler feet | Reinforced nylon base with steel threaded stem | |
| drawer pulls | Recessed black plastic integrated handles | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| pedestal storage configuration | Two soft-close drawers separated by two open storage cubbies | |
|---|---|---|
| cable management access | One 60 mm diameter desktop cable grommet | |
| leveler adjustment | Threaded feet rotate to adjust height up to 10 mm | |
| privacy divider function | Fabric-wrapped panel blocks direct line of sight across worktop | |
| drawer operation | Smooth pull-out action with integrated stop to prevent full accidental removal | |
| support structure design | Angled left A-frame leg eliminates knee obstruction for comfortable seated entry | |
| surface functionality | Stain and heat resistant melamine finish tolerates hot drink mugs and office supplies | |
| assembly configuration | Knock-down flat pack assembly with cam-lock and bolt hardware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| home office workspace | Suitable for dedicated home study spaces for remote work and study use | |
|---|---|---|
| open plan office employee workstation | Designed for low-partition open office layouts for individual staff workstations | |
| small business administrative workspace | Appropriate for reception, admin, or startup office general work areas | |
| shared co-working space desk | Configured for flexible co-working environments with privacy and storage | |
| student study desk | Usable for dormitory or student bedroom desk setup with integrated storage | |
| small space workspace solution | Compact footprint fits tight spaces without requiring separate storage furniture |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial office use | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements for pedestal drawer units | |
| EN 13722:2004 | Furniture assessment of surface resistance to abrasion for worktop finishes |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural performance and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer slide performance and load capacity |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural integrity | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for worktop and cabinet substrate quality | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances, for formaldehyde emission |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural integrity; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for worktop and cabinet substrate quality; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances, for formaldehyde emission; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
