Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2800 x 1400 x 750 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Per-side work surface depth | 610 mm | |
| Central knee clearance height | 670 mm | |
| Work surface top thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Cable grommet diameter | 60 mm | |
| Side storage pedestal width | 800 mm | |
| Desktop hutch height above work surface | 350 mm | |
| Diamond privacy screen height | 300 mm | |
| Hairpin leg rod diameter | 10 mm | |
| X-brace leg mounting plate thickness | 4 mm | |
| Drawer internal height | 150 mm | |
| Under-desk open shelf clearance | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Work surface static load capacity | 113 kg | |
|---|---|---|
| Drawer slide cycle life | 50000 cycles | |
| Door hinge cycle life | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface and storage panels | 18mm E1 grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Legs and support frames | Powder-coated matte black carbon steel with 10mm rod diameter | |
| Privacy dividers | Powder-coated steel wire with diamond lattice pattern | |
| Drawer slides and hinges | Cold-rolled steel with zinc plating | |
| Cable management components | ABS plastic grommets with removable caps | |
| Storage door and drawer fronts | Matte grey melamine finish over MDF core |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Face-to-face two-user layout | Opposed work positions separated by central low dividers | |
|---|---|---|
| Integrated cable routing | Surface grommets feed cables to under-desk open storage channels | |
| Mixed under-desk storage | Combines open CPU shelves, lockable door cabinet, and two file drawers per pedestal | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff zones | Suitable for two-person collaborative teams in open office layouts | |
|---|---|---|
| Small business work areas | Ideal for startup and small team offices requiring integrated storage |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2016 | Office furniture - work tables and desks, safety requirements | |
|---|---|---|
| EN 15372:2016 | Furniture - strength, durability and safety for office storage furniture | |
| EN 13722:2004 | Office furniture - office work chairs and tables, dimensional requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products - structural performance and durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for storage units - performance and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance requirements for office desks and workstations | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of formaldehyde emission |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3327-2017: Performance requirements for office desks and workstations; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of formaldehyde emission; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
