3-Person Linear Office Workstation Cluster with Wire Mesh Dividers and Side Storage Shelf (model WS-CL3-LIN-5400) is listed under Open Workstation, with overall dimensions of 5400 × 780 × 730 mm and main material of Particle‑board (PB). Load capacity: 91 kg. Certifications: Open-plan,linear,layout,integrated,fixed,drawer,pedestals,wire,mesh,privacy,dividers,cable,management,channel,attached,side,storage,shelf. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 5400 x 780 x 730 mm | |
|---|---|---|
| Per-user work surface width | 1800 mm | |
| Work surface thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Desk divider height above worktop | 495 mm | |
| Divider panel thickness | 30 mm | |
| Seated knee clearance height under worktop | 670 mm | |
| Knee clearance depth per position | 600 mm | |
| Fixed drawer pedestal width | 400 mm | |
| Drawer internal height | 150 mm per drawer | |
| Attached side storage shelf dimensions | 1000 x 300 x 700 mm | |
| Shelf tier vertical clearance | 300 mm | |
| Rear cable channel opening size | 410 x 50 mm | |
| Frame tube profile | 60 x 30 mm | |
| Leveling foot adjustment range | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Work surface static load capacity per position | 91 kg | |
|---|---|---|
| Total workstation net weight | 260 kg | |
| Recommended user capacity | 3 people | |
| Surface scratch resistance rating | 2000 cycles | |
| Surface stain resistance class | Grade 1 | |
| Commercial product warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm E1-grade melamine-faced particleboard with 2mm ABS edge banding | |
|---|---|---|
| Frame and understructure | 1.2mm thick powder-coated rectangular steel tubing with dual cross bracing | |
| Privacy dividers | 4mm thick diamond-pattern black wire mesh with steel mounting brackets | |
| Drawer pedestals | 18mm melamine-faced particleboard cabinet fronts and bodies with metal drawer slides | |
| Side storage shelf | 3.5mm thick black powder-coated wire grid with tubular steel support frame | |
| Leveling feet | Reinforced nylon base with steel threaded adjustment stems |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Recessed rear cable channel runs full length of workstation to route power and data cords | |
|---|---|---|
| Privacy separation | Wire mesh dividers mounted between adjacent work positions to reduce visual distraction | |
| Under-desk storage | Fixed integrated 2-drawer pedestals provide lockable storage for office supplies and files | |
| Side supply storage | Open 2-tier wire shelf attached to workstation end for documents, plants and small office items |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan corporate office spaces | Fits 3 staff in compact linear layout to maximize dense office floor plan efficiency | |
|---|---|---|
| Startup and co-working environments | Integrated storage and dividers reduce need for additional separate furniture |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to worktop and frame performance | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional and mechanical safety requirements for seated work positions | |
| EN 1335-2:2018 | Office chair stability test reference for workstation seated clearance compatibility |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for drawer and pedestal load and cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desktop and cabinet components | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks, applicable to structural stability and load testing | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood-based furniture panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desktop and cabinet components; 2. GB/T 3327-2016: Performance test methods for office desks, applicable to structural stability and load testing; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood-based furniture panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
