| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2180 x 1600 x 780 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static load capacity | 100 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| hinge cycle rating | 80000 cycles | |
| unit net weight | 68 kg | |
| laminate surface abrasion resistance | 2000 cycles | |
| adjustable floor glide adjustment range | 10 mm | |
| recommended user weight capacity | 150 kg | |
| product warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop substrate | E1 grade MDF board | |
|---|---|---|
| desktop surface finish | Scratch-resistant dark wood grain melamine laminate | |
| support legs | Powder-coated dark grey steel tubing, 1.5mm wall thickness | |
| cabinet panels | E1 grade particleboard with dark grey matte melamine finish | |
| edge banding | 2mm thick PVC edge banding with 45° bevel | |
| drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| drawer lock | Zinc alloy keyed cam lock | |
| floor glides | Nylon adjustable leveling glides | |
| cable management grommets | ABS plastic 60mm diameter desk grommets | |
| modesty panel | 18mm thick matching dark grey melamine particleboard | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| fixed height work surface | 780mm fixed desktop height optimized for standard office chair seated use | |
|---|---|---|
| dual CPU storage bays | Open dedicated bays under side return sized for two full-size ATX computer towers | |
| lockable top drawer | Key-locked shallow drawer for secure storage of valuables and small documents | |
| enclosed lower cabinet | Single-door closed cabinet for concealed storage of bulk office supplies | |
| upper open shelving | Three divided open shelf compartments for books, decor and frequently accessed items | |
| integrated cable management | 60mm desktop grommets plus under-desk cable tray for cord organization | |
| reversible return orientation | Side storage return supports left or right mounting to fit office layout | |
| adjustable floor leveling | Nylon glides adjust 10mm to stabilize desk on uneven floor surfaces | |
| splayed leg stability | Angled steel leg design distributes desktop load to minimize wobble during writing and typing | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| executive private office | Suitable for manager and director offices as a primary workstation with integrated storage | |
|---|---|---|
| home office workspace | Ideal for dedicated home offices requiring ample work and computer equipment storage | |
| open office manager pod | Appropriate for team lead workstations in open plan office layouts | |
| recommended seating pairing | Pairs with standard mid-back wheeled office chairs with 480 mm seat height | |
| equipment compatibility | Supports dual monitor setups, two desktop PCs, and standard office peripherals | |
| finish matching | Dark wood and dark grey finish coordinates with dark textured wall and neutral flooring palettes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural load testing | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office work tables dimensional and mechanical safety requirements, applicable for clearance verification | |
| EN 13722:2004 | Furniture storage units strength and durability requirements, applicable for cabinet and drawer testing |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for panel construction and finish quality | |
|---|---|---|
| GB/T 3327-2016 | Office desk performance test methods, applicable for static load and stability verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1 grade board acceptance | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable for laminate durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for panel construction and finish quality; 2. GB/T 3327-2016: Office desk performance test methods, applicable for static load and stability verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1 grade board acceptance; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable for laminate durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
