Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2800 x 1400 x 1100 mm | |
|---|---|---|
| Worksurface height from floor | 750 mm | |
| Per-user worksurface width | 1200 mm | |
| Per-user worksurface depth | 700 mm | |
| Under-desk knee clearance height | 690 mm | |
| Center privacy divider height above worksurface | 350 mm | |
| Desktop panel thickness | 25 mm | |
| Side storage cabinet panel thickness | 18 mm | |
| PVC edge banding thickness | 2 mm | |
| Splayed metal leg wall thickness | 1.5 mm | |
| Cable grommet diameter | 60 mm | |
| Under-desk CPU bay internal width | 250 mm | |
| Side open storage shelf clearance height | 300 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Overall workstation net weight | 165 kg | |
|---|---|---|
| Worksurface uniform static load capacity | 300 kg | |
| Recommended user weight capacity per seat | 120 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Hinge operational cycle rating | 80000 cycles | |
| Standard warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface | E1-grade melamine-faced chipboard, 25mm thick, 2mm PVC edge banding | |
|---|---|---|
| Side cabinet body | 18mm thick melamine-faced engineered wood, taupe and light beige finish | |
| Support legs | Powder-coated off-white steel, splayed angular design, 1.5mm wall thickness | |
| Center privacy divider | Fabric-upholstered terracotta padded panel, PB core, 32mm thick | |
| Open shelf interiors | Matching melamine-faced engineered wood, dark terracotta inner shelf surfaces | |
| Lockable drawer | Engineered wood drawer box, metal key lock, 3-section ball-bearing slides | |
| Cabinet door | Vertical woodgrain melamine panel, metal hinge, matching taupe finish | |
| Elevated monitor shelf | Melamine-faced engineered wood, central metal support bracket | |
| Adjustable feet | Nylon height-adjustable glides at cabinet base | |
| Hardware | Zinc-plated steel connector bolts, cam locks, and shelf supports | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Two-person side-by-side seating | Separated by central fabric divider to reduce visual distraction between users | |
|---|---|---|
| Integrated side storage | Open adjustable shelves, 1 lockable drawer, and 1 closed door cabinet for shared storage | |
| Under-desk CPU compartments | Dedicated open bays sized for full-size desktop towers with rear cable access | |
| Integrated cable management | 60mm desk grommets, under-desk cable routing channels for power and data cords | |
| Raised central monitor shelf | Elevated platform to place monitor riser or small office supplies off main worksurface | |
| Height-adjustable cabinet glides | Rotating nylon feet to level the storage unit on uneven carpet or hard floors | |
| Keyed drawer lock | Secures personal items and documents in the top side cabinet drawer | |
| Modular knock-down assembly | Flat-packed components for on-site assembly with included hardware and manual | |
| Stain-resistant worksurface finish | Melamine surface resists liquid spills and everyday scuffs for commercial office use | |
| Lockable drawer internal dimensions | 400 x 350 x 120 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan corporate office staff areas | Provides dedicated separated workspaces for two staff with integrated storage | |
|---|---|---|
| Small business admin departments | Compact footprint combines desk and storage to save floor space | |
| Coworking and shared office spaces | Durable commercial construction supports daily high-traffic use | |
| Home office for two users | Neutral beige/taupe color scheme fits residential work spaces | |
| Call center and back-office operations | Divider screen reduces cross-talk between adjacent seated staff | |
| Startup office open work areas | Modular design allows reconfiguration as team size changes | |
| Government and institutional office spaces | Neutral finish and durable construction meets public sector furniture standards |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural load testing | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and ergonomic requirements | |
| EN 14073-2:2004 | Office storage furniture safety and strength requirements for cabinet components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for static load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for cabinet and drawer durability | |
| ANSI/BIFMA X7.1-2020 | Formaldehyde and TVOC emission standard for office furniture products |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction quality | |
|---|---|---|
| GB/T 3327-2020 | Performance requirements for office desks and workstations, applicable to structural stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1-grade board verification | |
| GB/T 4897.3-2003 | Specification for particleboard for furniture use, applicable to core material quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction quality; 2. GB/T 3327-2020: Performance requirements for office desks and workstations, applicable to structural stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1-grade board verification; 4. GB/T 4897.3-2003: Specification for particleboard for furniture use, applicable to core material quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
