Automatic mm / inch conversion · Core engineering specifications
| Overall L-shape footprint | 2180 x 1390 x 750 mm | |
|---|---|---|
| Desktop thickness | 30 mm | |
| Edge band thickness | 2 mm | |
| Main desktop depth | 800 mm | |
| Side return cabinet width | 1200 mm | |
| Knee clearance height under desktop | 670 mm | |
| Knee clearance width | 1000 mm | |
| CPU compartment internal dimensions | 300 x 600 x 500 mm | |
| Open upper shelf depth | 300 mm | |
| Drawer internal height | 120 mm | |
| Lower storage cabinet internal height | 500 mm | |
| Metal Y-trestle leg section | 60 x 30 mm rectangular steel tube | |
| Steel leg wall thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Desktop static load capacity | 136 kg | |
|---|---|---|
| Cable grommet cable capacity | 12 cables | |
| Product net weight | 160 kg | |
| Recommended user weight support | 136 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet hinge cycle rating | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Standard warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main desktop | 30mm E1-grade MDF core with dark walnut wood-grain melamine laminate | |
|---|---|---|
| Storage return carcass | 25mm E1-grade particleboard with dark gray matte melamine finish | |
| Edge treatment | 2mm thick PVC edge banding with 45° beveled edges | |
| Y-shaped support leg | 2mm thick powder-coated matte silver steel tubing | |
| Leveling feet | Nylon adjustable feet with 10mm height adjustment | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Cabinet hinges | Cold-rolled steel soft-close concealed hinges | |
| Drawer lock | Zinc alloy keyed cam lock with 2 keys | |
| Surface coating | Scratch-resistant, water-repellent melamine top coat | |
| Leveling foot base pad | Non-marking TPE rubber pad to protect flooring | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Dedicated CPU compartment | Open lower bay in return cabinet sized for full-size desktop towers | |
|---|---|---|
| Locking utility drawer | Key-locked upper drawer for secure storage of small office valuables | |
| Closed lower storage cabinet | Hinged door compartment for concealed storage of office supplies | |
| Integrated cable management | 80mm diameter cable grommet on desktop for routing monitor and power cords | |
| Adjustable leveling feet | 10mm vertical adjustment on cabinet base to compensate for uneven floors | |
| Fixed work surface height | 750mm working height optimized for standard ergonomic office chairs | |
| Fixed L-shape configuration | Permanently attached return cabinet for stable corner office placement | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Designed for corporate manager or CEO offices requiring dedicated work and storage space | |
|---|---|---|
| Home office workspace | Suitable for large home offices supporting multi-monitor setups and document storage | |
| Small professional studio | Works for design or consulting studios needing organized work and reference storage | |
| Seated workstation configuration | Optimized for use with standard ergonomic office chairs at 750mm work height | |
| Corner placement layout | L-shape design fits neatly into room corners to maximize floor space |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial use | |
|---|---|---|
| EN 527-2:2016 | Office work tables, dimensional requirements for seated workstations | |
| EN 13722:2004 | Furniture, strength and durability of storage units for office use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to drawer and shelf performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural stability | |
|---|---|---|
| GB/T 3327-2020 | Performance requirements for office desks, applicable to desktop and drawer load ratings | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor use | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural stability; 2. GB/T 3327-2020: Performance requirements for office desks, applicable to desktop and drawer load ratings; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor use; 4. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
