| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1900 x 1600 x 762 mm | |
|---|---|---|
| Tabletop thickness | 19 mm | |
| Edge band thickness | 2 mm | |
| Main work surface dimensions | 1400 x 700 mm | |
| Side return dimensions | 1000 x 500 mm | |
| Knee clearance height | 720 mm | |
| Knee clearance width | 900 mm | |
| Drawer internal dimensions | 480 x 400 x 120 mm | |
| Enclosed cabinet internal dimensions | 480 x 450 x 600 mm | |
| Open shelf dimensions | 480 x 400 x 280 mm per tier | |
| U-shaped leg wall thickness | 1.2 mm | |
| Leveler foot height adjustment | 15 mm | |
| Edge overhang on work surface | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Assembled product weight | 70 kg | |
|---|---|---|
| Static work surface load capacity | 100 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Cabinet hinge cycle rating | 80000 cycles | |
| Surface scratch resistance rating | 2 N | |
| Recommended maximum user weight at desk | 136 kg | |
| Standard limited warranty period | 12 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | 18mm E1-grade engineered MDF core | |
|---|---|---|
| Storage cabinet panels | 16mm E1-grade particleboard core | |
| Left leg support frame | Powder-coated square steel tube | |
| Surface finish | Matte white thermally fused melamine | |
| Edge banding | 2mm thick PVC edge trim | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Lock hardware | Zinc alloy keyed cam locks | |
| Leveler feet | Nylon base with steel threaded stem | |
| Cabinet door hinge | Steel concealed soft-close hinges | |
| Open shelf partitions | 16mm thick matching melamine particleboard | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Lockable top drawer | Keyed lock secures contents, extends fully on ball-bearing slides | |
|---|---|---|
| Lockable side cabinet | Keyed door lock secures enclosed storage, level interior shelf for organization | |
| Dual-tier open shelving | Two fixed open shelves provide easy-access storage for books and accessories | |
| Floor level adjustment | Threaded nylon leveler feet adjust 15mm to stabilize desk on uneven floors | |
| Cantilevered work surface design | Open knee bay without center obstruction allows free chair movement | |
| Matte stain-resistant surface | Wipe-clean melamine surface resists common office spills and marks | |
| Reversible layout adaptability | Desk assembly allows return installation on left or right side | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Provides spacious work surface and secure storage for manager workspaces | |
|---|---|---|
| Home office workstation | Compact L-shape fits residential study rooms for remote work use | |
| Small business workstation | Affordable fixed-height desk suitable for startup and small office setups | |
| Dual-monitor workstation | 1400mm main work surface supports two monitors plus laptop and peripherals | |
| Study space for students | Open shelves hold reference books, lockable storage secures personal items |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applies to desk performance | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applies to cabinet and drawers | |
| EN 14074:2004 | Office furniture movable components durability requirements, applies to slides and hinges |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to panel construction | |
|---|---|---|
| GB/T 3327-2018 | Performance standards for office desks and work tables, applies to stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applies to MDF/particleboard | |
| GB/T 4897.3-2015 | Particleboard specification for furniture use, applies to storage panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to panel construction; 2. GB/T 3327-2018: Performance standards for office desks and work tables, applies to stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applies to MDF/particleboard; 4. GB/T 4897.3-2015: Particleboard specification for furniture use, applies to storage panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
