Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1600 x 1200 x 1100 mm | |
|---|---|---|
| work surface height | 750 mm | |
| worktop thickness | 25 mm | |
| central privacy screen height above worktop | 350 mm | |
| knee clearance height under worktop | 650 mm | |
| knee clearance depth per user | 600 mm | |
| integrated pedestal width | 400 mm | |
| single CPU bay internal dimensions | 220 x 450 x 480 mm | |
| angled steel leg wall thickness | 1.5 mm | |
| PVC edge band thickness | 2 mm | |
| cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| worktop static uniform load capacity | 120 kg | |
|---|---|---|
| drawer slide cycle durability | 50000 cycles | |
| surface scratch resistance grade | Grade 3 | |
| surface stain/heat resistance grade | Grade 3 | |
| net weight of workstation | 95 kg | |
| applicable user count | 2 | |
| standard product warranty | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| worktop substrate | E1-grade MFC particle board | |
|---|---|---|
| worktop surface finish | Light oak woodgrain melamine laminate | |
| edge banding | 2mm thick PVC edging | |
| support legs | Off-white powder-coated square steel tubing | |
| cabinet body | Off-white melamine coated MFC panels | |
| central divider screen | Grey woven fabric upholstered panel | |
| drawer lock | Zinc alloy keyed cam lock | |
| leveling feet | Nylon and steel adjustable glides | |
| hardware components | Zinc-plated steel screws and connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| central fabric divider | Blocks direct line of sight between opposite users to reduce visual distraction | |
|---|---|---|
| integrated CPU storage | Dual open bays under worktop hold two desktop towers to free work surface space | |
| lockable storage drawer | Keyed top drawer secures personal items and confidential office documents | |
| cable management system | Central recessed grommets route power and data cables from desktop to under-desk area | |
| modular connection capability | Designed to connect to additional matching workstations for larger open-plan layouts | |
| adjustable pedestal leveling | Turnable glides under cabinet base adjust to eliminate wobble on uneven floors | |
| work surface layout | Split equal work areas for two users, each with 800mm wide usable work frontage | |
| lockable drawer internal depth | 400 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open plan office areas | Suits staff team zones requiring moderate separation between adjacent co-workers | |
|---|---|---|
| small startup offices | Compact footprint fits two users in limited floor space with integrated storage | |
| call center and administrative departments | Face-to-face layout supports quick team communication while reducing distraction | |
| staff training and shared work zones | Flexible layout works for paired project work or shared task stations | |
| modern co-working spaces | Neutral light oak and off-white finish fits contemporary office design schemes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for general structural compliance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture work chair dimensional reference for chair compatibility with workstation | |
| EN 14073-2:2004 | Office storage furniture safety requirements for integrated pedestal and drawer components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural performance and durability testing of work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer load and cycle performance of integrated pedestal |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MFC cabinet and worktop components | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to panel components | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to desk strength and stability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MFC cabinet and worktop components; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to panel components; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to desk strength and stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
