Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W×D×H) | 2800 × 1200 × 1100 mm | |
|---|---|---|
| Worktop height above floor | 750 mm | |
| Individual work surface width per seat | 700 mm | |
| Worktop depth per side | 600 mm | |
| Desk divider height above worktop | 350 mm | |
| Divider cork panel dimensions (per unit) | 1100 × 300 mm | |
| Knee clearance height under worktop | 650 mm | |
| Knee clearance width at outer angled leg | 600 mm | |
| Storage pedestal depth (per unit) | 600 mm | |
| Storage pedestal width (per unit) | 400 mm | |
| Drawer internal usable height (top shallow drawer) | 100 mm | |
| Drawer internal usable height (bottom deep drawer) | 450 mm | |
| CPU compartment internal dimensions (W×D×H) | 250 × 550 × 500 mm | |
| Angled steel leg splay angle from vertical | 15° | |
| Worktop height above finished floor | 750 mm | |
| Worktop depth per seating side | 600 mm | |
| Worktop panel thickness | 25 mm | |
| Desk divider height above worktop surface | 350 mm |
Net weight / load capacity / users / durability
| Total unit net weight () | 210 kg | |
|---|---|---|
| Worktop static load capacity per seat | 100 kg | |
| Maximum recommended user weight per seat | 120 kg | |
| Divider cork panel pin retention capacity | Holds 20+ pinned notes/photos without tearing | |
| Stability: maximum lateral tilt before tipping | 12° | |
| Durability: drawer slide cycle rating | 50000 open/close cycles | |
| Edge impact resistance | Withstands 10N·m impact without chipping | |
| Seating capacity | 4 people | |
| Maximum user weight per seat (combined user + equipment) | ≥120 kg | |
| Cork divider pin retention performance | Holds ≥25 pinned paper notes/photos without surface tearing or pin hole enlargement after 1000 pin insertions | |
| Lateral stability: tilt angle before tipping | ≥12° | |
| Drawer slide cycle rating | ≥50000 full open/close cycles | |
| Drawer slide static load rating per drawer | ≥25 kg for shallow stationery drawer, ≥40 kg for deep filing drawer | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panel | 25mm thick E1-grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Desk divider frame | 18mm thick dark brown melamine-faced MDF with rounded corners | |
| Divider tack surface | 6mm thick natural cork panel | |
| Outer support legs | 2mm thick powder-coated matte black steel angled splay legs with 10mm diameter steel cross-brace | |
| Storage cabinet carcass | 18mm thick dark charcoal melamine-faced particleboard with matte finish | |
| Drawer fronts | 18mm thick light beige melamine-faced MDF with recessed integrated black plastic handle | |
| Drawer slides | 3-section full-extension cold-rolled steel ball-bearing slides | |
| Adjustable feet | 20mm diameter black nylon height-adjustable glides, 10mm adjustment range | |
| Cable management grommet on divider | White ABS plastic 60mm diameter cable port | |
| Desk divider outer frame | 18mm thick dark brown melamine-faced MDF with rounded corner edges, secured with black plastic end caps at corners | |
| Storage pedestal carcass | 18mm thick dark charcoal matte melamine-faced particleboard, constructed with cam-lock fasteners for rigid box assembly | |
| Drawer front panels | 18mm thick light beige matte melamine-faced MDF, fitted with recessed integrated black ABS pull handles | |
| Drawer hardware | 3-section full-extension cold-rolled steel ball-bearing slides, zinc-plated corrosion-resistant finish | |
| Base leveling glides | 20mm diameter black nylon height-adjustable glides, 10 mm vertical adjustment range, fitted to all pedestal base corners | |
| Cable management components | White ABS plastic 60mm cable grommets fitted to divider frames, with below-desk space for optional 15kg load capacity steel cable tray | |
| Pedestal base support pads | 3mm thick black anti-slip rubber pads under glides, prevent floor scuffing and reduce movement during use | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cork divider tack function | Accepts push pins to attach notes, photos and documents without damaging panel surface, provides 350mm high visual privacy between opposite-facing seats | |
|---|---|---|
| Storage drawer configuration (per pedestal) | 1 shallow stationery drawer for pens/small supplies, 1 deep filing drawer compatible with A4/legal suspension file folders | |
| Open CPU storage bay | Open under-desk bay between adjacent pedestals accommodates mid-tower desktop computers, with open rear for cable routing | |
| Cable management routing | Integrated cable grommet in divider frame routes power and data cables from worktop devices to below-desk area, with space in central cavity for cable trays | |
| Height-adjustable glides | Nylon glides at base of all pedestals adjust 10 mm to level the desk on uneven floors, prevents wobble | |
| Modular connection system | Units join with integrated steel connecting brackets to create extended workstation runs, no visible external fasteners on front surfaces | |
| Worktop edge ergonomics | Rounded front edges reduce forearm pressure during extended typing, 2mm PVC edge resists chipping from impact | |
| Leg footrest function | Horizontal steel cross-brace on outer angled legs acts as a fixed footrest for outer seat users | |
| Cork divider dual function | Provides 350mm high seated visual privacy between opposing face-to-face seats, and accepts push pins to attach notes, photos and documents without permanent panel damage, with visible pinned items demonstrating tack function in image | |
| Integrated pedestal storage (per unit) | Each two-drawer pedestal positioned between adjacent seats includes 1 shallow top drawer for small stationery and supplies, 1 deep bottom drawer compatible with A4/foolscap suspension hanging files, with full-extension slides for complete drawer access | |
| Open CPU storage bays | Two open unenclosed under-desk bays located between pedestals accommodate standard mid-tower desktop computers, with open rear panels for passive ventilation and unobstructed cable routing to worktop devices | |
| Integrated cable routing | 60mm diameter cable grommets in divider frames route power, monitor and data cables from worktop devices to below-desk area, with central under-worktop cavity space for mounting cable trays to contain loose cables | |
| Leveling adjustability | Nylon glides at all pedestal base points adjust 10 mm vertically to level the workstation on uneven finished floors, eliminating wobble during typing or equipment use | |
| Modular expandability | Adjacent workstation units connect via hidden steel connecting brackets to create extended linear runs of workstations, with no visible external fasteners on exposed front surfaces for a clean finish |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 4 cartons | |
|---|---|---|
| Largest carton dimensions (L×W×H) | 2850 × 650 × 100 mm | |
| Total shipping gross weight | 250 kg | |
| Total shipping volume (CBM) | 0.52CBM | |
| Assembly time on site | 2.5person-hours | |
| 20ft GP container loading quantity | 54units | |
| 40ft HQ container loading quantity | 128units | |
| Largest shipping carton dimensions (L×W×H) | 2850 × 650 × 110 mm | |
| Total shipping volume | 0.53CBM | |
| On-site assembly time | 2.5person-hours |
Recommended spaces / users / usage modes
| Open-plan office work areas | Suitable for 4-person teams in corporate open offices, provides dedicated individual work space with partial visual privacy to reduce distraction | |
|---|---|---|
| Start-up and co-working spaces | Two-tone neutral finish fits flexible co-working environments, integrated storage eliminates need for separate pedestals to save floor space | |
| Administrative and back-office departments | Filing drawer capacity supports document storage for admin, HR and finance roles, cork dividers allow easy pinning of reminders and to-do lists | |
| Call center and customer service zones | 700mm seat width provides sufficient space for monitor, keyboard and call center equipment, cable management keeps work surfaces uncluttered | |
| Project team work zones | Can be joined in runs to create larger team blocks, cork dividers support display of project schedules and notes for cross-team visibility | |
| Recommended paired seating | Pair with mid-back ergonomic office chairs with seat height range 520 mm to match 750mm worktop height for optimal seated ergonomics | |
| Open-plan corporate office areas | Suitable for 4-person operational teams in corporate open offices, provides dedicated individual work space with partial visual privacy to reduce cross-seat distraction while maintaining team visibility | |
| Start-up and co-working flexible spaces | Neutral two-tone dark/light finish fits flexible co-working environments, integrated storage eliminates need for separate rolling pedestals to reduce per-seat floor space footprint | |
| Recommended pairing configuration | Pair with mid-back ergonomic office chairs with 520 mm seat height adjustment range to match 750mm worktop height for optimal seated ergonomics, with 5-star base and casters suitable for hard or carpeted office floors |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to safety and dimensional requirements for office work desks, specifies minimum worktop depth 600mm and leg clearance for seated use | |
|---|---|---|
| EN 12521:2015 | Applies to strength, durability and stability requirements for commercial office furniture, specifies load test levels for frequent use office workstations | |
| EN 13986:2004+A1:2015 | Applies to wood-based panel performance characteristics for use in furniture construction |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to performance requirements for office desks, specifies worktop static load of 448N (100lbf) per seat position, drawer cycle testing of 50000 operations | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applies to performance requirements for storage pedestals integrated into desks, specifies drawer load ratings and stability when drawers are fully extended |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to dimensional tolerances and stability requirements for office desks, specifies minimum knee clearance height 600mm and worktop height range 760 mm for general office use | |
|---|---|---|
| GB 18580-2017 | Applies to formaldehyde emission limits for wood-based panels used in the desk carcass and worktop, requires E1 grade emission ≤0.124mg/m³ for indoor office furniture | |
| GB/T 10357.1-2013 | Applies to mechanical performance test methods for desks, specifies static load, impact and durability test procedures for work surfaces and storage components |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to dimensional tolerances and stability requirements for office desks, specifies minimum knee clearance height 600mm and worktop height range 760 mm for general office use; 2. GB 18580-2017: Applies to formaldehyde emission limits for wood-based panels used in the desk carcass and worktop, requires E1 grade emission ≤0.124mg/m³ for indoor office furniture; 3. GB/T 10357.1-2013: Applies to mechanical performance test methods for desks, specifies static load, impact and durability test procedures for work surfaces and storage components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
