Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1200 x 1100 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 135 kg | |
|---|---|---|
| Work surface static load capacity | 100 kg per seat | |
| Recommended user capacity | 2 people | |
| Surface abrasion resistance | 2000 cycles | |
| Frame static load rating | 300 kg | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | 25mm thick melamine-faced particleboard, 2mm ABS edge banding | |
|---|---|---|
| Steel support frame | 1.5mm thick powder-coated light gray square steel tubing | |
| Storage cabinet panels | 18mm thick melamine-faced particleboard, matching wood-grain and light gray finish | |
| Central desk divider | 18mm thick light gray particleboard core, fabric-covered front face | |
| Hardware components | Zinc-alloy lock cores, steel drawer slides, plastic adjustable feet | |
| Edge trim details | 2mm thick impact-resistant ABS edge banding on all exposed panel edges | |
| Modesty panel | 15mm thick orange melamine-faced panel, mounted between front steel legs | |
| Cabinet shelf surfaces | 18mm thick melamine-faced particleboard, level-adjustable support pegs | |
| Foot pads | Non-slip TPE rubber pads at base of steel legs | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Work surface layout | Two adjacent independent work zones separated by a central privacy divider | |
|---|---|---|
| Integrated upper storage | Tiered open shelves above the work surface for document and supply storage | |
| Lower lockable storage | Two key-locked cabinet doors for secure personal file and item storage | |
| Right-side drawer unit | One upper shallow drawer and one lower deep cabinet for stationery and file storage | |
| Cable management access | Notched cutout behind central divider for desk cable routing | |
| Leveling adjustment | Adjustable plastic feet at storage cabinet base to compensate for uneven floors | |
| Modular configuration compatibility | Pre-drilled connection points to link additional identical workstation units | |
| Open side shelving | Vertical open cubbies between lockable cabinets for quick-access item storage | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office spaces | Suitable for 2-person team clusters in corporate open office layouts, provides individual privacy and storage | |
|---|---|---|
| Small business offices | Ideal for startup or small firm work areas with limited floor space, combines desk and storage in one unit | |
| Shared work environments | Suitable for co-working spaces with assigned seating, lockable storage secures personal belongings | |
| Recommended seating pairing | Pair with two mid-back ergonomic office chairs on casters for standard seated work positions | |
| Installation requirement | Requires flat, level indoor office flooring, no permanent wall fixing needed for freestanding placement |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for commercial use | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and mechanical performance requirements | |
| EN 13722:2004 | Furniture storage units strength and durability requirements for cabinet components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desks performance standard for structural load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for cabinet, shelf and drawer durability | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and environmental compliance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to all panel components | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks, applicable to work surface and frame | |
| GB 18584-2001 | Formaldehyde emission limit for interior wooden furniture, required for indoor air quality | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to structural load validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to all panel components; 2. GB/T 3327-2016: Performance requirements for office desks, applicable to work surface and frame; 3. GB 18584-2001: Formaldehyde emission limit for interior wooden furniture, required for indoor air quality; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to structural load validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
