| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimension | 1200 x 1200 x 1100 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Per-user desktop static load capacity | 100 kg | |
|---|---|---|
| Product net weight | 85 kg | |
| Recommended user count | 2 | |
| Privacy divider sound attenuation (A-weighted) | 8 dB | |
| Leveling foot adjustment range | 10 mm | |
| Drawer slide cycle rating | 50000 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 18mm E1 grade particleboard core | |
|---|---|---|
| Desktop surface finish | 25mm thick wear-resistant melamine laminate | |
| Privacy divider core | Medium density fiberboard with fabric upholstery | |
| Support leg construction | Powder-coated cold-rolled steel box tubing | |
| Modesty panel material | 18mm thick melamine-faced particleboard | |
| Storage drawer construction | 15mm thick particleboard drawer sides, metal slide rails | |
| Lock mechanism | Zinc alloy keyed cam locks | |
| Leveling feet | Nylon base height-adjustable glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Center privacy divider function | Fixed fabric screen blocks direct line of sight between two facing users | |
|---|---|---|
| Integrated cable management | Recessed cable grommet at desk center routes power/data cords under desktop | |
| Lockable drawer storage | One upper drawer and one lower filing drawer per user, keyed independently | |
| Seated leg access | Open knee bay between support leg and storage pedestal for comfortable seated posture | |
| Floor leveling adjustment | Rotating nylon glides adjust to compensate for uneven office floors | |
| Modesty panel coverage | Full side modesty panel blocks view of under-desk leg area from aisle | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office application | Suitable for general office open plan work areas | |
|---|---|---|
| Small team workspace | Ideal for 2-person teams requiring shared desktop access and individual lockable storage | |
| Administrative work area | Appropriate for administration, customer service and data entry positions | |
| Call center deployment | Suitable for high-density call center installations | |
| Co-working space usage | Applicable to co-working hot desk areas with assigned temporary storage |
EU Market Access Requirements* EN Standards
| Office desk safety standard | EN 527:2011 | |
|---|---|---|
| Office desk dimensional standard | EN 527:2002 | |
| Surface wear resistance standard | EN 14322:2017 |
US and Canada office-furniture standards
| Desk load and durability standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Storage unit performance standard | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Desk dimensional standard | GB/T 3326 | |
|---|---|---|
| Panel furniture safety standard | GB/T 3324 | |
| Formaldehyde emission standard | GB 18580 |
This product must meet the following technical requirements: 1. Desk dimensional standard: GB/T 3326; 2. Panel furniture safety standard: GB/T 3324; 3. Formaldehyde emission standard: GB 18580; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
