Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Per-user desktop work area width | 1200 mm | |
| Desktop panel thickness | 32 mm | |
| Privacy screen height above desktop | 350 mm | |
| Privacy screen panel thickness | 16 mm | |
| Under-desk seated knee clearance height | 620 mm | |
| Central drawer pedestal width | 450 mm | |
| Central drawer pedestal depth | 600 mm | |
| Single drawer internal height | 260 mm | |
| Support leg tube cross-section | 40 x 40 mm | |
| Desk edge trim thickness | 1 mm | |
| Pedestal back panel thickness | 6 mm | |
| Pedestal leveling foot diameter | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop uniform static load capacity | 120 kg | |
|---|---|---|
| Total assembled product weight | 130 kg | |
| Recommended maximum user capacity | 2 people | |
| Metal frame powder coating thickness | 80 um | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Leveling foot vertical adjustment range | 15 mm | |
| Commercial use warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 32mm dark wood-grain laminated MFC panel with 1mm PVC edge banding | |
|---|---|---|
| Privacy dividers | 16mm fiberboard core wrapped in grey textured fabric upholstery | |
| Support legs | 40x40x1.5mm steel tube with matte black powder coating and champagne gold accent strip | |
| Central pedestal body | 16mm dark wood-grain laminated particleboard with matte black side panel | |
| Drawer slides | Three-part full-extension cold-rolled steel ball-bearing slides | |
| Pedestal feet | Nylon adjustable leveling glides with non-slip rubber pads |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Desktop privacy dividers | Clamp-mounted 350mm-high fabric panels block seated cross-user line of sight | |
|---|---|---|
| Central locking pedestal | Two lockable drawers provide secure shared or individual office storage | |
| Angled splayed leg frame | Outward-angled legs increase stance stability and maximize leg room per user | |
| Leveling adjustment | Nylon glides adjust to eliminate wobble on uneven office floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Largest shipping carton dimensions | 2450 x 650 x 80 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office staff work areas | Dual side-by-side layout supports dense team seating with privacy separation | |
|---|---|---|
| Small startup and co-working spaces | Integrated storage reduces need for additional furniture per workstation |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial use | |
|---|---|---|
| EN 15372:2016 | Furniture, durability and strength for non-domestic office seating work surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, covering load, stability and durability for office desks |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktop and pedestal panel performance | |
|---|---|---|
| GB/T 3325-2017 | Test methods for metal furniture, applicable to steel frame structural integrity | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, for indoor air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktop and pedestal panel performance; 2. GB/T 3325-2017: Test methods for metal furniture, applicable to steel frame structural integrity; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, for indoor air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
