PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Distributed worktop load	80 kg
Drawer load per drawer	15 kg
Shelf load per shelf	20 kg
Distributed worktop static load	80 kg
Pedestal case top load	40 kg
Drawer slide load per drawer	15 kg
Drawer slide endurance	50,000 open-close cycles
Open shelf static load per shelf	20 kg
Hinge or drawer-front durability	50,000 cycles
Desktop divider panel load	10 kg horizontal load

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Worktop panel	25 mm engineered-wood particleboard core with walnut-look melamine face and 2 mm PVC edge band.
Storage case panels	18 mm graphite-gray melamine-faced engineered wood, doweled and cam-fastened into a box structure.
Drawer fronts	18 mm engineered-wood core with walnut-look melamine finish matching the worktop and integrated pull recess.
Drawer boxes	15 mm graphite melamine board or steel-sided drawer construction mounted on side extension slides.
Open shelf board	18 mm graphite melamine-faced engineered wood fixed within the pedestal frame.
Support legs	40 mm round black powder-coated steel tube with 1.2 mm wall thickness and welded top fixing plate.

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Two-position drawer storage	Two drawers provide separated storage for stationery and documents, each rated to 15 kg.
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

No data is available for this section.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LSW-1400-1200-DIV

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LSW-1400-1200-DIV

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LSW-1400-1200-DIVOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The LSW-1400-DIV is an unbranded L-shaped executive workstation designed for users seeking a structured work surface, integrated storage, and a degree of visual separation in a single office layout. Its angled configuration creates a main work zone and a connected return side, giving the desk an executive presence while supporting multitasking, side reference materials, or meetings at the edge of the workstation. An upholstered desktop divider adds a softer visual element above the worktop and helps define personal workspace in shared or semi-open environments. The walnut-look worktop is paired with graphite-gray storage panels and black steel legs, producing a balanced contrast between warm wood-effect surfaces and darker functional components. The 50 mm finished top thickness contributes to the desk’s substantial appearance, while the storage return anchors the layout and brings storage within easy reach. Its rectangular drawer fronts use integrated pull recesses, maintaining a clean front elevation without protruding handles. The worktop is constructed from a 25 mm engineered-wood particleboard core with a walnut-look melamine face and 2 mm PVC edge banding. Storage case panels, drawer fronts, drawer boxes, and open shelving use melamine-faced engineered wood in matching walnut or graphite finishes, selected by component. The case is built as a doweled and cam-fastened box structure, while drawer boxes may be supplied in graphite melamine board or steel-sided construction with side extension slides. Support is provided by black powder-coated steel legs with welded top fixing plates. Practical features include two drawers for stationery and document separation, fixed open shelving, and a pedestal-style storage return that also helps support the layout. The workstation is rated for a distributed worktop load of 80 kg, with each drawer rated to 15 kg, each shelf to 20 kg, and the pedestal case top to 40 kg. Drawer slides are rated for a 15 kg load and 50,000 open-close cycles. An 80 mm cable opening and 120 mm deep cable tray support cable organization, with a reference capacity for ten power or data cables and a tray load of 10 kg. The main seating position offers 680 mm high and 900 mm wide knee clearance. This configuration suits private offices, managerial workspaces, open-plan task areas, consultancy rooms, and residential studies where an expansive desk and built-in storage are required. Procurement teams should plan for assembly, access, and placement before delivery, noting the multi-carton packaging, separate return or pedestal packing, and 180 kg packaged gross weight. The desk should be specified where its walnut-and-graphite finish, storage layout, divider profile, and cable provisions match the intended workspace. Buyers should also review room dimensions, seating position, floor protection, cable routing, and available installation support, rather than treating the product as a compact single-box desk.

L-Shaped Executive Workstation with Storage Return and Desktop Divider Specifications
