| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 600 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Product net weight | 85 kg | |
|---|---|---|
| Static worktop load capacity per seat | 120 kg | |
| Maximum supported users | 2 | |
| Adjustable foot leveling capacity | 15 mm | |
| Surface abrasion resistance | 2000 cycles | |
| Structure service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | 25mm E1-grade particleboard with matte white melamine laminate | |
|---|---|---|
| Left support frame | 1.5mm thick powder-coated steel cantilever leg | |
| Pedestal cabinet bodies | 0.8mm thick cold-rolled steel with white powder coating | |
| Drawer locks | Zinc alloy keyed cam locks, one per pedestal | |
| Cable management grommets | ABS plastic soft-seal grommets | |
| Central cable tray | Cold-rolled steel wire management tray under worktop center | |
| Leveling feet | Nylon base with steel threaded stem | |
| Pedestal modesty panels | Integrated steel panel covering seated leg area | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Work zone layout | Two independent seated positions separated by central cable management | |
|---|---|---|
| Lockable storage | One lockable storage pedestal per seating position | |
| Cable routing | Dual surface grommets plus under-desk central cable tray | |
| Floor leveling | Six adjustable nylon feet across frame and pedestals | |
| Storage configuration | One upper utility drawer per pedestal, open under-desk knee space | |
| Modular assembly | Bolt-connected frame and pedestal components | |
| Surface usability | Scratch-resistant matte melamine finish resists office wear | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 3 | |
|---|---|---|
| Largest shipping carton dimensions | 2850 x 650 x 120 mm | |
| Total shipping gross weight | 95 kg | |
| Total shipment volume | 0.32 CBM | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 82 units | |
| Packaging protection | 5-layer corrugated carton with EPS edge foam | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
Recommended spaces / users / usage modes
| Open plan office spaces | Supports two staff per unit to maximize dense workspace layouts | |
|---|---|---|
| Call center and admin work areas | Durable surface and integrated storage for daily high-frequency use | |
| Training room installations | Uniform dimensions allow rowed arrangement for group training setups | |
| Small startup offices | Compact dual-seat design provides cost-effective workstations for small teams |
EU Market Access Requirements* EN Standards
| Office furniture stability | EN 527:2002 office work desk stability | |
|---|---|---|
| Surface wear resistance | EN 14322:2017 melamine board abrasion | |
| Steel component corrosion resistance | EN 13722:2004 metal furniture coating |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| Worktop formaldehyde emission | GB/T 39600E1 grade | |
|---|---|---|
| Structural strength test | GB/T 10357.1desk mechanical performance | |
| Coating adhesion requirement | GB/T 4893.4furniture surface adhesion |
This product must meet the following technical requirements: 1. Worktop formaldehyde emission: GB/T 39600E1 grade; 2. Structural strength test: GB/T 10357.1desk mechanical performance; 3. Coating adhesion requirement: GB/T 4893.4furniture surface adhesion; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
