Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1600 x 600 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Edge banding thickness | 2 mm | |
| Rear privacy divider height | 200 mm | |
| Rear privacy divider thickness | 18 mm | |
| Seated knee clearance height | 620 mm | |
| Seated knee clearance width | 760 mm | |
| Right storage pedestal width | 400 mm | |
| Right storage pedestal depth | 580 mm | |
| Lower cabinet door internal height | 500 mm | |
| Central CPU compartment width | 440 mm | |
| Steel A-frame leg section | 60 x 30 mm | |
| Steel frame wall thickness | 1.2 mm | |
| Desktop power caddy size | 120 x 80 x 60 mm | |
| Green cross-brace width | 80 mm | |
| Leveling glide height adjustment | 10 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 120 kg | |
|---|---|---|
| Seating capacity | 2 users | |
| Net product weight | 55 kg | |
| Steel frame durability cycles | 10000 | |
| Drawer slide cycle rating | 50000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | 25mm E1 grade engineered wood with light oak laminate finish | |
|---|---|---|
| Support frame | 1.2mm thick powder-coated steel tube, white finish with green cross-brace | |
| Storage cabinet panels | 18mm thick melamine-faced MFC, light oak and off-white finish | |
| Privacy divider | 18mm thick matte white MFC panel mounted on silver metal support posts | |
| Power module housing | Green ABS plastic housing with integrated AC power sockets | |
| Hardware components | Zinc-plated steel bolts, plastic leveling glides, standard drawer lock |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Desktop power access | Integrated desktop power caddy with 2 AC sockets for device charging | |
|---|---|---|
| Secured storage | Lockable upper drawer in right pedestal for personal office item storage | |
| CPU equipment storage | Central open under-desk compartment sized to hold two desktop computer towers | |
| Cable management | Desktop cable grommet and under-desk routing space to organize workstation wiring |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office zones | Suitable for shared staff work areas, two-person capacity per unit | |
|---|---|---|
| Small business workspaces | Ideal for startup and small team offices with integrated storage and power |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial use | |
|---|---|---|
| EN 527-2:2016 | Office work tables, dimensional requirements for seated workstation use | |
| EN 1335-2:2018 | Office furniture seating safety, referenced for knee clearance compatibility |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, defining strength, durability and stability requirements |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop and cabinet panels | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel support frame | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to engineered wood components | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to structural load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop and cabinet panels; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel support frame; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to engineered wood components; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to structural load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
