Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 1600 x 1100 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 100 kg | |
|---|---|---|
| Total product net weight | 125 kg | |
| Recommended user count | 2 | |
| Desktop divider acoustic attenuation | 15 dB | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 5 years | |
| Drawer dynamic load rating | 25 kg per drawer | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Cabinet hinge cycle rating | 80000 open/close cycles | |
| Melamine surface abrasion resistance | 2000 rub cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panels | 18mm thick E1 grade particleboard with matte melamine finish | |
|---|---|---|
| Support legs | 50x50mm square powder-coated dark gray steel tube | |
| Cabinet carcass | 18mm thick E1 grade particleboard with dark gray melamine finish | |
| Cabinet door/drawer fronts | 18mm thick E1 grade particleboard with light beige melamine finish | |
| Desktop divider panel | 25mm thick MDF core with brown woven fabric upholstery | |
| Tabletop cable grommet | Black ABS plastic with integrated metal monitor arm mount base | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Drawer lock | Zinc alloy keyed cam lock | |
| Cabinet support feet | Injection-molded PP adjustable leveling feet | |
| Front support legs | 50x50mm 1.5mm wall thickness dark gray powder-coated square steel tube | |
| Storage cabinet carcass | 18mm E1-grade particleboard with dark charcoal melamine finish | |
| Cabinet door and drawer fronts | 18mm E1-grade particleboard with light beige matte melamine finish |
Adjustment / rotation / tilt / mobility / storage features
| Desktop privacy partition | Fabric-covered divider runs full worktop depth between two users | |
|---|---|---|
| Cable management system | Recessed 80mm central grommet routes power and data cables to under-desk wire tray, eliminating desktop cord clutter | |
| Lockable storage drawers | Full-extension drawers lock via keyed cam lock to secure personal office supplies and documents, opening fully for unobstructed access | |
| Open storage shelving | Upper open cabinet compartments provide instant access to frequently used files and office peripherals without door operation | |
| Floor leveling adjustment | Threaded PP feet adjust up to 15mm to stabilize the workstation on uneven commercial flooring, eliminating wobble | |
| Monitor arm compatibility | Reinforced metal mounting plate under central grommet supports single or dual monitor arms up to 12kg per arm, reducing desktop footprint | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office work zones | Configured for 2 adjacent employees, providing separated work surfaces and shared side storage to maximize open floor space efficiency | |
|---|---|---|
| Small startup office spaces | Integrated storage eliminates need for separate filing cabinets, reducing total furniture footprint for limited floor area offices | |
| Government administration work areas | Lockable drawers support secure document storage, and durable surfaces meet high-traffic daily use requirements for public sector offices | |
| Temporary project team workspaces | Quick assembly and reconfigurable layout supports short-term project teams in co-working or flexible office environments | |
| Branch bank customer service stations | Dual work positions allow two staff to process customer requests with separated privacy and organized storage for forms and supplies |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural and finish acceptance | |
|---|---|---|
| GB/T 3327-2016 | Office furniture - desks, applicable for dimensional and performance criteria for office work surfaces | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for panel material indoor air quality requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural and finish acceptance; 2. GB/T 3327-2016: Office furniture - desks, applicable for dimensional and performance criteria for office work surfaces; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for panel material indoor air quality requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
