Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2800 x 2400 x 1150 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Per individual workstation desktop | 1200 x 700 mm | |
| Desktop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Under-desk knee clearance height | 673 mm | |
| Central raised shelf height above desktop | 300 mm | |
| Diamond mesh privacy screen height | 300 mm | |
| Integrated storage pedestal dimensions per user | 400 x 600 x 650 mm | |
| Cable grommet diameter | 60 mm | |
| Outer hairpin leg rod diameter | 10 mm | |
| Steel support beam wall thickness | 1.2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum static load per work position | 113 kg | |
|---|---|---|
| Drawer slide rated load | 25 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Cable tray load capacity | 10 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Total unit net weight | 290 kg | |
| Recommended user weight capacity per position | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop and cabinet panels | E1 grade melamine-faced particle board, distressed light wood grain finish | |
|---|---|---|
| Frame, legs and mesh screens | Powder-coated dark grey carbon steel | |
| Edge banding | 2 mm thick PVC edge trim, grey accent color | |
| Storage cabinet door and drawer fronts | Melamine-faced MDF, matte dark grey finish | |
| Leveling feet | Reinforced nylon with adjustable steel screw base | |
| Hardware and fasteners | Zinc-plated steel bolts and cam locks |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Recessed desktop cable grommets route to under-desk cable trays for each workstation | |
|---|---|---|
| Personal storage | Each user position includes 1 lockable utility drawer and 1 lockable cabinet door | |
| CPU storage | Vented lower compartments with airflow grilles for desktop computer tower placement | |
| Desk leveling | Adjustable feet on all support points compensate for uneven office floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office spaces | Ideal for 4-person team clusters in call centers, admin departments or co-working spaces | |
|---|---|---|
| Staff work areas requiring integrated storage | Suitable for teams needing personal locked storage and dedicated CPU space without separate cabinets |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance testing | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety requirements, applicable to clearance and work surface sizing | |
| EN 13722:2004 | Furniture storage units strength and durability requirements, applicable to integrated cabinet pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to drawer and cabinet durability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel construction and finish | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks and workstations, applicable to structural load and stability | |
| GB 18584-2001 | Formaldehyde emission limit for interior wooden furniture, applicable to engineered wood panel cores |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel construction and finish; 2. GB/T 3327-2016: Performance requirements for office desks and workstations, applicable to structural load and stability; 3. GB 18584-2001: Formaldehyde emission limit for interior wooden furniture, applicable to engineered wood panel cores; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
