Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2400 x 1530 x 1140 mm | |
|---|---|---|
| Desktop surface height | 750 mm | |
| Desktop panel thickness | 25 mm | |
| Central privacy divider height above desktop | 400 mm | |
| Knee clearance height under desktop | 700 mm | |
| Side storage return unit dimensions | 1600 x 450 x 720 mm | |
| Per-person work surface width | 1200 mm | |
| Open storage cubby internal height | 320 mm | |
| Drawer internal usable depth | 400 mm | |
| Cable grommet opening diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 168 kg | |
|---|---|---|
| Product net weight | 95 kg | |
| Recommended user count | 2 | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary work surface | 25mm melamine-faced engineered wood, 2mm PVC edge banding | |
|---|---|---|
| Structural legs and support frame | 1.5mm thick powder-coated black steel, splayed angled design | |
| Central privacy divider panel | Fabric-upholstered fiberboard with integrated cable channel | |
| Side storage return cabinet body | 18mm melamine-faced engineered wood, matte dark gray/black finish | |
| Storage drawer fronts | 18mm light wood grain melamine engineered wood, black metal pull handles | |
| Drawer slides | Cold-rolled steel three-section ball-bearing slides, zinc-plated finish | |
| Drawer locks | Zinc alloy keyed cam locks, one key per lock | |
| Leveling feet | Reinforced nylon adjustable feet, 10mm adjustment range | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Work surface separation | Central desktop divider creates visual privacy between two adjacent seated users | |
|---|---|---|
| Cable management | Recessed desktop cable grommet routes power and data cords from surface to under-desk area | |
| Lockable document storage | Two key-locked drawers on side return secure personal documents and office supplies | |
| Open supply storage | Four open cubby shelves on return and under desk hold frequently used office items | |
| Floor leveling | Adjustable feet on base compensate for uneven floor surfaces to keep desktop level | |
| Drawer operation | Ball-bearing slides allow full drawer extension with smooth, quiet opening and closing | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff seating | Provides dedicated divided workspaces for two employees in open office layouts | |
|---|---|---|
| Small startup team work areas | Compact L-shaped footprint fits limited office space while offering storage and workspace for two staff | |
| Home office shared workspace | Suits two people working from home with separate visual zones and secure personal storage | |
| Studio or co-working space hot-desking | Durable commercial-grade construction supports high-traffic shared co-working use |
EU Market Access Requirements* EN Standards
| Office furniture safety and stability | EN 527:2011 | |
|---|---|---|
| Office work surface dimensional requirements | EN 527:2002+A1:2019 | |
| Office storage unit performance | EN 14073:2004 |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| Desk panel formaldehyde emission | GB/T 39600E1 grade | |
|---|---|---|
| Desk structural strength and stability | GB/T 3326 | |
| Metal surface coating durability | GB/T 1993 |
This product must meet the following technical requirements: 1. Desk panel formaldehyde emission: GB/T 39600E1 grade; 2. Desk structural strength and stability: GB/T 3326; 3. Metal surface coating durability: GB/T 1993; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
