Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1600 x 762 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desk static load capacity | 260 kg | |
|---|---|---|
| Surface abrasion resistance | 2000 cycles | |
| Recommended maximum user weight per position | 136 kg | |
| Product net weight | 120 kg | |
| Frame structure static load rating | 300 kg | |
| Warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | 38mm thick melamine-faced particleboard with 2mm ABS edge banding | |
|---|---|---|
| Storage pedestals | 18mm thick matte grey melamine particleboard with integrated lock cores | |
| Support frame and legs | 1.2mm thick powder-coated steel angled X-legs and cross beams | |
| Privacy divider | Fabric-covered MDF core panel mounted to desktop center | |
| Drawer slides | Full-extension cold-rolled steel ball-bearing slides | |
| Cable management components | ABS cable grommets and under-desk steel cable trays | |
| Hardware fasteners | Zinc-plated steel cam locks, screws and connecting bolts | |
| Floor glides | Adjustable nylon glides on leg and pedestal bases | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual-sided seating layout | Supports two seated users facing each other with divided personal work zones | |
|---|---|---|
| Lockable drawer storage | Each user pedestal includes lockable drawers for personal files and office supplies | |
| Cable routing system | Desktop grommets and under-desk trays route power and data cables out of sight | |
| Floor leveling adjustment | Adjustable glides on legs and pedestals compensate for uneven floor surfaces | |
| Privacy separation | Low central divider blocks direct line of sight between facing users to reduce distraction | |
| File storage compatibility | Lower pedestal compartments fit standard A4/letter size hanging file folders | |
| Modular expandability | Desk units can be connected in clusters to build larger open-plan workstation layouts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office spaces | Suitable for 2-person team clusters in modern open office layouts, supports focused and collaborative work | |
|---|---|---|
| Small business team offices | Ideal for startup or small office setups requiring integrated storage without additional furniture purchase | |
| Corporate staff work areas | Matches modern dark wood/grey office interior palettes for executive support or departmental work zones | |
| Modular workstation expansions | Can be grouped into 4, 6 or 8-person clusters for scalable open office fit-outs | |
| Project team work zones | Supports paired work for design, admin or operations teams who need adjacent shared work surfaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables and desks safety, strength and durability requirements for commercial use | |
|---|---|---|
| EN 527-2:2016 | Dimensional requirements for office desks to support ergonomic seated work | |
| EN 13722:2004 | Performance requirements for office furniture storage pedestals and drawer units | |
| EN 71-3:2019 | Migration of certain elements requirement for surface finishes on furniture components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products covering safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for storage units including lockable pedestal file drawers | |
| ANSI/BIFMA e3-2019 | Sustainability standard for furniture materials, emissions and end-of-life management |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to panel desk structural performance | |
|---|---|---|
| GB/T 3327-2017 | Performance test standards for office desks and workstations, applicable to stability and load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to desktop and pedestal panels | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to panel desk structural performance; 2. GB/T 3327-2017: Performance test standards for office desks and workstations, applicable to stability and load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to desktop and pedestal panels; 4. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
