Automatic mm / inch conversion · Core engineering specifications
| Overall footprint dimensions | 2800 x 1500 x 1200 mm | |
|---|---|---|
| Worksurface height from floor | 750 mm | |
| Privacy divider height from floor | 1200 mm | |
| Individual L-shaped workstation segment length | 1400 mm | |
| Individual L-shaped workstation segment depth | 700 mm | |
| Knee clearance height under worksurface | 650 mm | |
| Knee clearance width per user position | 800 mm | |
| Central storage pedestal width | 800 mm | |
| Central storage pedestal depth | 600 mm | |
| Worksurface panel thickness | 25 mm | |
| PVC edge banding thickness | 3 mm | |
| Privacy divider panel thickness | 30 mm | |
| Cylindrical steel leg diameter | 60 mm | |
| Raised cable management shelf height above worksurface | 200 mm | |
| Desk cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm |
Net weight / load capacity / users / durability
| Total product net weight | 180 kg | |
|---|---|---|
| Worksurface static uniform load capacity | 100 kg | |
| Single drawer slide load rating | 45 kg | |
| Drawer slide open/close cycle rating | 50000 cycles | |
| Cabinet hinge open/close cycle rating | 80000 cycles | |
| Recommended maximum user weight capacity per position | 150 kg | |
| Surface scratch resistance rating | 2000 revolutions | |
| Commercial warranty period | 5 years | |
| Available color option count | 6 | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface panels | 25mm E1-grade melamine-faced particleboard with 3mm PVC edge banding | |
|---|---|---|
| Central cabinet panels | 18mm E1-grade melamine-faced particleboard with matching PVC edge banding | |
| Support legs | 60mm diameter powder-coated dark grey cylindrical steel with brass accent rings | |
| Privacy dividers | 30mm thick MDF core wrapped in beige fabric with dark grey corner end caps | |
| Drawer hardware | Cold-rolled steel ball-bearing full-extension slides with zinc alloy locks and ABS plastic handles | |
| Cable management components | Dark grey ABS plastic grommets with raised steel-framed MDF cable shelf | |
| Floor glides | Injection-molded nylon adjustable glides at leg and cabinet base | |
| Structural connecting hardware | Zinc-plated steel cam lock and screw fasteners for knock-down assembly | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central pedestal storage configuration | 4 lockable drawers plus 2-tier open front-facing storage cubbies for shared supplies | |
|---|---|---|
| Privacy divider function | Fixed desktop-mounted screens block direct line of sight between adjacent face-to-face users for seated privacy | |
| Cable management system | Recessed desk grommets route cables from worksurface to raised central shelf for organized power and data routing | |
| Storage drawer operation | Full-extension ball-bearing slides allow full access to drawer contents, with keyed lock securing all pedestal drawers | |
| Leveling adjustment | Adjustable nylon floor glides on all legs and cabinet base compensate for uneven office flooring | |
| Modular assembly capability | Knock-down design allows disassembly and reconfiguration of workstation segments for office layout changes | |
| Open cubby storage function | Dual open front-facing shelves provide easy-access storage for frequently used documents and office supplies | |
| Worksurface orientation | Dual opposite-facing L-shaped surfaces support two users in a face-to-face seating arrangement for collaborative or independent work | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office layouts | Suitable for 2-person work clusters in commercial open offices, providing dedicated workspace with privacy separation | |
|---|---|---|
| Small team work areas | Ideal for collaborative two-person teams requiring shared storage and separate individual work surfaces | |
| Startup office spaces | Cost-effective modular solution for growing offices needing quick setup and future reconfiguration capability | |
| Government and corporate admin areas | Durable commercial-grade construction suitable for high-traffic administrative staff work zones | |
| Co-working space dedicated desks | Provides private, fixed work positions for co-working members with integrated storage and cable management | |
| Call center and back-office operations | Compact dual-station design maximizes floor space efficiency for high-density task-based work environments | |
| Home office dual-use setups | Can be used in large home offices for two people working from home with organized cable and storage |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable as safety and dimensional standard for office worktables and desks | |
|---|---|---|
| EN 1335-1:2020 | Applicable as ergonomic reference standard for office workstation seated user dimensions | |
| EN 14073-2:2004 | Applicable as safety standard for office storage cabinets and drawer units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable as performance standard for desk products covering load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable as performance standard for office storage units covering drawer and shelf load |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable as general technical standard for wooden office furniture quality requirements | |
|---|---|---|
| GB 18584-2001 | Applicable as mandatory standard for formaldehyde emission limits of wooden furniture materials | |
| GB/T 35607-2017 | Applicable as performance standard for green product evaluation of wooden office furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable as general technical standard for wooden office furniture quality requirements; 2. GB 18584-2001: Applicable as mandatory standard for formaldehyde emission limits of wooden furniture materials; 3. GB/T 35607-2017: Applicable as performance standard for green product evaluation of wooden office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
