Automatic mm / inch conversion · Core engineering specifications
| Overall panel dimensions | 1200 x 25 x 450 mm | |
|---|---|---|
| Compatible desk top thickness | 50 mm | |
| Mounting clamp overhang below desk | 60 mm | |
| Panel edge radius | 3 mm | |
| Clamp contact pad width | 40 mm | |
| Clearance above seated user eye level | 0 mm | |
| Effective coverage width per panel | 1200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net panel weight | 4 kg | |
|---|---|---|
| Maximum static accessory load on panel face | 6 kg | |
| Clamp mounting static load capacity | 20 kg | |
| Recommended user seating width per panel | 1200 mm | |
| Noise reduction coefficient (NRC) | 0.9 | |
| Product warranty period | 36 months | |
| Fabric abrasion resistance | 50000 double rubs | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Panel outer covering | Woven polyester fabric upholstery | |
|---|---|---|
| Panel core | Recycled polyester fiber acoustic board | |
| Core-laminated padding | 10mm thick polyurethane foam | |
| Mounting clamps | 1.5mm thick powder-coated steel | |
| Clamp contact pads | Non-marking EPDM rubber | |
| Panel edge binding | Matching fabric tape | |
| Internal frame reinforcement | 3mm thick MDF perimeter strip | |
| Fastening hardware | Zinc-plated steel screws and adjustment knobs | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Mounting mechanism | Tool-free C-clamp attachment | |
|---|---|---|
| Sightline privacy function | Blocks seated cross-workstation direct eye contact | |
| Acoustic dampening function | Reduces speech noise transmission between adjacent seats | |
| Panel face utility | Accepts push pins for notes and lightweight attachments | |
| Position adjustability | Slides along desk edge before clamp tightening | |
| Installation requirement | No permanent desk modification | |
| Surface cleanability | Stain-resistant fabric allows spot cleaning with mild detergent | |
| Modular compatibility | Connects to additional side panels for 3-sided cubicle enclosures | |
| Seated eye-level block height from desk surface | 450 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office workstations | Creates individual privacy between adjacent seated employees | |
|---|---|---|
| Hot-desking shared workspaces | Quickly reconfigures to divide temporary work zones | |
| Student study desks in co-working areas | Reduces cross-distraction during focused individual work | |
| Reception and admin work areas | Defines personal work space without blocking overhead light | |
| Call center seating rows | Improves speech privacy between adjacent agents | |
| Home office double desks | Separates shared desk space for two remote workers |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Applicable for stability testing of desk-mounted office furniture components | |
|---|---|---|
| EN 14465:2004 | Applicable for upholstery fabric abrasion and performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2020 | Applicable for storage and panel workstation component structural performance testing | |
|---|---|---|
| ANSI/BIFMA e3-2020 | Applicable for evaluating sustainability attributes of office furniture panels | |
| ANSI/BIFMA X5.5-2021 | Applicable for desk and desk-mounted accessory load and stability testing |
Standards applicable to China-market projects
| GB/T 21027-2007 | Applicable for office workstation screen dimensional stability and structural durability testing | |
|---|---|---|
| GB/T 19889.3-2005 | Applicable for measuring airborne sound insulation for desk partition screens | |
| GB 20286-2006 | Applicable for fire retardant performance requirements for public space upholstered furniture | |
| GB/T 17657-2013 | Applicable for testing physical and chemical properties of wood-based panel cores |
This product must meet the following technical requirements: 1. GB/T 21027-2007: Applicable for office workstation screen dimensional stability and structural durability testing; 2. GB/T 19889.3-2005: Applicable for measuring airborne sound insulation for desk partition screens; 3. GB 20286-2006: Applicable for fire retardant performance requirements for public space upholstered furniture; 4. GB/T 17657-2013: Applicable for testing physical and chemical properties of wood-based panel cores; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
