Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions | 2400 x 1200 x 750 mm | |
|---|---|---|
| Per-user work surface dimensions | 1200 x 600 mm | |
| Desktop thickness | 25 mm | |
| Under-desk knee clearance height | 673 mm | |
| Knee clearance depth per seat | 600 mm | |
| Central mobile pedestal dimensions | 400 x 500 x 650 mm | |
| Frosted privacy divider dimensions | 1200 x 380 x 5 mm | |
| Cable grommet diameter | 60 mm | |
| Pedestal caster diameter | 50 mm | |
| Side panel support leg thickness | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 300 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Pedestal caster dynamic load rating | 50 kg per caster | |
| Applicable user count | 2 users | |
| Unit net weight | 154 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Product warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop surface | 25mm E1-grade particleboard with matte grey melamine laminate | |
|---|---|---|
| Desktop edge banding | 2mm thick PVC edge sealing | |
| Support frame and legs | 1.2mm thick powder-coated light grey steel | |
| Privacy dividers | 5mm thick light green frosted acrylic | |
| Mobile pedestal body | 0.8mm thick cold-rolled steel with matte grey powder coat | |
| Drawer slides | Zinc-plated steel full-extension ball-bearing slides | |
| Pedestal casters | Black nylon swivel casters, 2 locking per unit | |
| Cable grommets | ABS plastic black/silver cable management grommets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual independent work zones | Separated by central pedestal and rear dividers to minimize cross-distraction between users | |
|---|---|---|
| Lockable central storage pedestal | Keyed lock secures top stationery drawer and lower file drawer for personal office storage | |
| Mobile pedestal movement | 5 swivel casters allow pedestal to be repositioned or removed for under-desk cleaning | |
| Integrated cable management | Rear grommets route monitor and laptop power cables below desk surface for uncluttered tops | |
| Floor leveling adjustment | Integrated feet on support legs compensate for uneven office floor surfaces | |
| Modular expansion capability | Pre-drilled connection brackets allow linking additional workstation units for larger open plans | |
| Pedestal drawer access | Full-extension slides provide complete access to rear of drawers without reaching | |
| Caster locking function | 2 lockable casters on each pedestal prevent unintended movement during stationary use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Provides two dedicated work positions with visual separation for team-based workspaces | |
|---|---|---|
| Small business and startup offices | Space-efficient layout maximizes floor area utilization for growing teams | |
| Call center and administrative zones | Clear work zoning and accessible storage support daily clerical and screen-based tasks | |
| Shared co-working spaces | Modular design allows reconfiguration to match changing workspace needs | |
| Recommended complementary seating | Pair with mid-back swivel task chairs with 480 mm adjustable seat height | |
| Adjacent storage configuration | Position matching low credenza storage units along rear walls for shared filing space |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office worktables mechanical safety requirements for stability and load capacity | |
| EN 1335-2:2009 | Office chair safety reference for complementary seating dimensional clearance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk products standard for static load, stability and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for pedestal drawer slide performance and lock durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to laminate desktop components | |
|---|---|---|
| GB/T 3325-2017 | Metal office furniture safety and performance requirements, applicable to steel frame and pedestal | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood-based panels, mandatory for desktop substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to laminate desktop components; 2. GB/T 3325-2017: Metal office furniture safety and performance requirements, applicable to steel frame and pedestal; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood-based panels, mandatory for desktop substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
