Automatic mm / inch conversion · Core engineering specifications
| Overall module dimensions (per 2-person unit) | 2400 x 1200 x 1100 mm | |
|---|---|---|
| Per-station work surface dimensions | 1200 x 600 mm | |
| Desktop surface height above floor | 750 mm | |
| Fabric divider height above desktop | 350 mm | |
| Divider panel thickness | 32 mm | |
| Desktop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Steel leg tube section | 50 x 50 mm | |
| Steel leg wall thickness | 1.5 mm | |
| Under-desk knee clearance height | 680 mm | |
| Knee clearance depth per station | 550 mm | |
| Central shared upper shelf dimensions | 1200 x 300 x 400 mm | |
| Under-desk pedestal dimensions | 1200 x 450 x 700 mm | |
| Desktop cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Per-station desktop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide durability (cycles) | 50000 | |
| Hinge/drawer hardware salt spray resistance | 72 hours | |
| Desktop surface abrasion resistance | 2000 cycles | |
| Fabric divider acoustic noise reduction | 15 dB | |
| Total unit net weight | 65 kg | |
| Recommended user capacity | 2 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | E1 grade particle board with melamine laminate finish | |
|---|---|---|
| Work surface edging | 2mm thick PVC edge banding, hot-melt sealed | |
| Support frame and legs | Powder-coated matte dark green steel square tubing | |
| Desktop privacy divider | Medium density fiberboard core upholstered with woven polyester fabric | |
| Central upper storage shelf | Melamine laminated particle board with matching dark green outer finish | |
| Under-desk pedestal drawer fronts | Contrast light beige/white laminated particle board | |
| Pedestal support feet | Injection molded nylon height-adjustable glides | |
| Hardware components (screws, connectors) | Zinc-plated cold-rolled steel | |
| Cable grommets | Flexible black rubber with brush insert | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | 80mm diameter rubber grommets at each station route power/data cables | |
|---|---|---|
| Shared upper storage | Dual-compartment open central shelf holds shared office supplies above divider | |
| Under-desk storage | 4-drawer central pedestal provides locked personal storage for opposite users | |
| Modular expansion | Knock-down steel connectors allow linking multiple modules into longer bench runs | |
| Floor leveling | Nylon glides on legs and pedestal adjust 10mm to compensate for uneven floors | |
| Privacy screening | Fabric divider blocks direct line of sight between opposite seated users | |
| Assembly design | Cam-lock and bolt assembly requires no specialized on-site tools | |
| Surface maintenance | Stain-resistant melamine surface wipes clean with standard office cleaning agents | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan corporate offices | Suited for clustered staff seating with integrated storage to reduce floor clutter | |
|---|---|---|
| Co-working flexible spaces | Modular design supports quick reconfiguration for changing team sizes | |
| Small business admin areas | All-in-one design includes storage and cable management for compact offices | |
| Government/institution back offices | Durable commercial construction supports daily high-use desk work | |
| Startup team work zones | Two-tone modern aesthetic fits contemporary office interior design schemes | |
| Call center seating zones | Low dividers provide partial privacy while enabling supervisor visibility |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Safety and strength requirements applicable for office work surfaces and support structures | |
|---|---|---|
| EN 1335-2:2018 | Stability reference for seating-adjacent office workstation layout clearances | |
| EN 1022:2018 | Stability testing reference applicable for freestanding office storage components |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable for wooden office furniture desktops and cabinet components | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit applicable for wood-based panel components, minimum E1 grade requirement | |
| GB/T 3327-2016 | Stability and structural performance requirements applicable for office desk units |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable for wooden office furniture desktops and cabinet components; 2. GB 18580-2017: Formaldehyde emission limit applicable for wood-based panel components, minimum E1 grade requirement; 3. GB/T 3327-2016: Stability and structural performance requirements applicable for office desk units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
