PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1400 × 1200 × 1100 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Distributed desktop static load	80 kg
Pedestal top load	30 kg
Top drawer load	10 kg
Open shelf load	15 kg
Lower cabinet load	25 kg
Suggested occupant capacity	1 person
Product net weight	52 kg
Drawer slide cycle target	50,000 cycles
Hardware warranty target	5 years
Top Static Load Reference	150 kg uniformly distributed

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Main worktop	25 mm engineered-wood panel with matte light-grey laminate and edge banding
Side-return top	Matching matte engineered-wood panel joined to the main desktop
Pedestal carcass	Grey wood-composite panels with durable laminate finish
Privacy screen	Smoked translucent acrylic or toughened-resin panel in a black metal support rail
Support legs	Silver powder-coated steel round tubes with angled bracing and floor pads
Hardware and cable ports	Black lock insert, cable grommets, screws and floor glides

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Privacy separation	A 350 mm high smoked screen blocks direct sight lines while retaining light transmission
Cable management	Two circular ports on the under-desk panel route monitor and power cables into the rear cavity
Personal storage	Right pedestal provides one lockable top drawer, one open document cubby and one lower closed cabinet
Stable support	Two splayed metal legs support the open leg side while the pedestal braces the right end

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Main carton dimensions	1480 x 760 x 120 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office workstation	Suited to one employee in open offices because the rear screen gives sight-line privacy without closing the knee bay
Supervisor or administrative seat	Suitable for daily computer work, document filing and locked personal storage in a compact L-shaped footprint

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WS-L1400-1200-PED-SCR

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WS-L1400-1200-PED-SCR

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WS-L1400-1200-PED-SCROpen Export Tool

Quick Actions

Post an RFQ

Product Description

The L-Shaped Staff Workstation with Privacy Screen and Lockable Side Pedestal is an unbranded office desk designed for a single user seeking a compact, organized workspace. Model WS-L1400-PED-SCR combines a modern right-hand L-shaped layout with integrated storage and a smoked privacy screen, making it well suited to open-plan offices and administrative or supervisory roles. Its form balances visual separation with openness: a 350 mm smoked translucent acrylic or toughened-resin screen, supported by a black metal rail, blocks direct sight lines while allowing light to pass through, so the knee bay remains accessible and the desk does not feel enclosed. The work surfaces use matte engineered-wood panels with light-grey laminate and edge banding; the side-return top matches the main desktop and joins it to form the L configuration. The main worktop panel is 25 mm thick, while the finished top thickness is 50 mm. Storage components use grey wood-composite panels with a durable laminate finish, creating a restrained contrast with the silver powder-coated steel legs and black hardware. The round steel legs feature angled bracing, splayed supports and floor pads, with an 80 mm main section and 2 mm metal wall. Two splayed metal legs support the open side, while the right-hand pedestal braces the opposite end. Functional details support daily desk work. The right pedestal includes a lockable top drawer for personal items, an open document cubby and a lower closed cabinet. Load capacity is rated at 80 kg distributed across the desktop, 30 kg on the pedestal top, 10 kg in the top drawer, 15 kg on the open shelf and 25 kg in the lower cabinet. Cable management is handled through two circular ports in the under-desk panel, each 80 mm in diameter, directing monitor and power leads into the rear cavity above a cable tray with 120 mm depth. Each main seat position offers 680 mm high and 900 mm wide effective knee clearance. This workstation is appropriate for one employee performing computer-based tasks, filing and routine administrative work. Procurement teams should note that it is delivered as a knock-down product requiring assembly, with a reference assembly time of 40 minutes per set. Packaging information varies by logistics record: one reference lists two cartons with a main carton measuring 1480 by 760 by 120 mm, while another lists four cartons with packaged gross weight of 180 kg per set, packaging volume of 1 m³ per set, and a packed main top dimension of 2500 by 1050 by 350 mm, with the return and pedestal packed separately. The product net weight is 52 kg. Buyers should confirm final carton count, delivery configuration and site access before ordering, and allow floor protection for the steel glides.

L-Shaped Staff Workstation with Privacy Screen and Lockable Side Pedestal Specifications
