PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2400 × 1400 × 1500 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Distributed desktop static load	80 kg
Storage shelf static load	25 kg per shelf
Drawer static load	20 kg
Return work-surface static load	50 kg
Fixed shelf static load	25 kg per shelf
Drawer slide durability	50,000 cycles
Door hinge durability	100,000 open-close cycles
CPU bay static load	30 kg
Cable-management load	5 kg
Top surface durability	50,000 abrasion cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Main worktop	25 mm wood-composite substrate with walnut-look melamine face and 2 mm PVC edge banding
Return worktop	25 mm wood-composite panel with walnut-look melamine surface and sealed matching edges
Carcase panels	18 mm greige melamine-faced composite panels with impact-resistant edge sealing
Hutch back and dividers	18 mm composite panels with low-sheen greige painted or melamine finish
Drawer front	18 mm composite panel with walnut-look melamine finish and integrated key lock
Lower door	18 mm composite slab door with vertical walnut-look melamine face and concealed hinges

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Lockable drawer face	420 x 350 mm
Lower lockable door compartment	420 x 500 x 560 mm
Desktop power and data module	Recessed 80 mm module provides socket access and supports laptop or monitor connection at the rear work zone
Cable routing	Cords pass from the 80 mm grommet into the under-desk channel and toward the equipment bay

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Private executive office	Use as a 2400 mm command desk for one manager, with laptop zone, secure files, and CPU storage in one footprint
Manager meeting area	Place guest seating at the open front edge for short discussions while keeping the return storage private

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017 General technical requirements for wooden furniture	applies to dimensional accuracy, edge sealing, panel fit, and finish acceptance.
GB/T 3325-2017 Test methods for metallic furniture	applies to strength and stability checks of the steel cantilever leg.
GB/T 10357 series furniture mechanical tests	recommended for desk static load, drawer durability, shelf load, and stability acceptance.
GB 18580-2017 Formaldehyde emission for interior decoration materials	applies to procurement limits for wood-based panels.

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017 General technical requirements for wooden furniture: applies to dimensional accuracy, edge sealing, panel fit, and finish acceptance.;
2. GB/T 3325-2017 Test methods for metallic furniture: applies to strength and stability checks of the steel cantilever leg.;
3. GB/T 10357 series furniture mechanical tests: recommended for desk static load, drawer durability, shelf load, and stability acceptance.;
4. GB 18580-2017 Formaldehyde emission for interior decoration materials: applies to procurement limits for wood-based panels.;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · RCV-2400-R-INTEGRATED

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · RCV-2400-R-INTEGRATED

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · RCV-2400-R-INTEGRATEDOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Integrated Reception Desk with Side Storage Hutch and Work Surface, model RCV-2400-R-INTEGRATED, is an unbranded two-tone reception workstation designed for front-of-house settings that require an organized work area, visitor-facing counter space, and concealed storage in one coordinated unit. Its right-return layout creates an L-shaped footprint with a broad main top, a side work surface, and a storage hutch that defines the reception boundary while keeping daily equipment and documents within reach. Walnut-look work surfaces contrast with greige painted or melamine-faced composite panels, giving the desk a contemporary commercial appearance suitable for neutral office interiors. The main and return worktops use 25 mm wood-composite panels with walnut-look melamine faces and matching sealed edges. The finished top presents a 50 mm thickness, while carcase panels, hutch components, drawer fronts, and the lower slab door use 18 mm composite construction. Main panels feature impact-resistant edge sealing, and the lower door operates on concealed hinges. Beige powder-coated metal cantilever legs support the structure; the main leg section is 80 mm with a 2 mm metal wall. Integrated cable and access hardware includes an 80 mm rear grommet, an under-desk channel, a cable tray with 120 mm depth, and a recessed 80 mm power and data module for socket access at the rear work zone. Functional storage is concentrated on the return. A walnut-look lockable drawer provides secure personal or operational storage, and the lower lockable door compartment offers enclosed space for equipment or files. The hutch includes shelving and dividers for reception materials, while fixed and open shelves support routine items. Cords route from the desktop opening into the under-desk channel and toward the equipment bay, supporting a cleaner monitor, laptop, or printer setup. The main seating position provides 680 mm high and 900 mm wide knee clearance. Rated static capacities are 80 kg distributed across the desktop, 50 kg on the return surface, 25 kg per shelf, and 20 kg in the drawer. Drawer slides are rated for 50,000 cycles and door hinges for 100,000 open-close cycles. Beyond reception, the desk is appropriate for a private executive office as a command desk with laptop space, secure files, and CPU storage, or in a manager meeting area with guest seating placed at the open front edge. Procurement planning should account for its substantial integrated form, return orientation, assembly requirements, and two-tone finish. The set is supplied as cartoned furniture, with separate packing for the main top and return or pedestal components. Buyers should confirm access routes, power and data outlet locations, cable management needs, lockable storage requirements, and whether the right-hand return matches the intended room layout.

Integrated Reception Desk with Side Storage Hutch and Work Surface Specifications
