Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 2400 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Lower cabinet drawer/cabinet static load | 50 kg | |
| Ball-bearing drawer slide cycle rating | 50000 cycles | |
| Cabinet door hinge open/close cycle rating | 80000 cycles | |
| Surface scratch resistance (Taber abrasion) | 400 cycles | |
| Wood panel moisture content | 10% | |
| Product net weight | 118 kg | |
| Recommended maximum user weight per seated position | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | E1 grade MDF substrate with light oak melamine laminate finish | |
|---|---|---|
| Side cabinet panels | E1 grade particleboard substrate with off-white matte melamine finish | |
| Support legs | Powder-coated light gray steel tubular A-frame frames | |
| Central privacy divider | MDF core with gray textured fabric tackable surface | |
| Edge banding | 2mm thick PVC matching panel finishes on all exposed panel edges | |
| Cabinet door hinge | Cold-rolled steel soft-close concealed hinges | |
| Drawer slides (if fitted) | Three-section full-extension ball-bearing steel slides | |
| Cable grommets | ABS plastic dual-port cable management fittings | |
| Leveling glides | Nylon base with threaded steel adjustable stems | |
| Shelf interior finish | Light wood grain melamine matching desktop finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Dual-position work surface | Two equal side-by-side work zones separated by a low central privacy screen to reduce visual distraction between users | |
|---|---|---|
| Integrated side storage | Combination of upper open adjustable shelves for frequently accessed documents and lower closed cabinet for concealed CPU/office supply storage | |
| Integrated cable management | Two circular desk-top cable grommets route power and data cables from work surface to under-desk area to eliminate desktop cord clutter | |
| Floor leveling adjustment | Threaded nylon glides at all leg and cabinet base points adjust to compensate for uneven floor surfaces for stable installation | |
| Soft-close cabinet doors | Concealed hinges dampen door closure to prevent slamming and reduce office noise | |
| Modular assembly | Knock-down panel and frame construction allows reconfiguration or relocation of the workstation for office layout changes | |
| Full-extension storage access | Cabinet slides allow full pull-out access to stored files and equipment without reaching into deep cabinet cavities | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff zones | Suitable for two adjacent staff positions, providing visual privacy without blocking open office sightlines | |
|---|---|---|
| Small business startup offices | Combines two work surfaces and integrated storage to maximize space efficiency in limited office floor areas | |
| Project team work areas | Dual adjacent work surfaces support collaborative team work between two team members while maintaining individual work zones | |
| Co-working space dedicated desks | Durable commercial construction and cable management support long-term assigned desk use for co-working members | |
| Matching task chair pairing | Works with standard mid-back mesh office task chairs with 5-star bases and casters for ergonomic seated use | |
| Project procurement bulk orders | Modular standard design supports bulk ordering for large office fit-out projects with consistent finish specifications |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables – Part 1: Dimensions, applicable to desktop height, clearance and dimensional ergonomic requirements | |
|---|---|---|
| EN 527-2:2016 | Office work tables – Part 2: Mechanical safety requirements, applicable to structural stability and load performance | |
| EN 14073-2:2004 | Office storage furniture – Part 2: Safety requirements, applicable to cabinet and shelf structural performance | |
| EN 14074:2004 | Office storage furniture – Test methods for strength and durability of moving parts |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard, applicable to desk structural load, stability and durability performance benchmarks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard, applicable to attached cabinet and shelf performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and cabinet panel performance, dimensional tolerances and finish quality | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to cabinet and desk substrate structural performance requirements | |
| GB/T 11718-2009 | Medium density fiberboard for furniture, applicable to desktop and divider core substrate requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, mandatory E1 ≤0.124mg/m³ emission requirement for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and cabinet panel performance, dimensional tolerances and finish quality; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable to cabinet and desk substrate structural performance requirements; 3. GB/T 11718-2009: Medium density fiberboard for furniture, applicable to desktop and divider core substrate requirements; 4. GB 18580-2017: Formaldehyde emission limits for wood-based panels, mandatory E1 ≤0.124mg/m³ emission requirement for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
